Home Assistant (Hass) is an open-source home automation platform running on Python 3.

Important: The information on this page is related to:

Sonoff-Tasmota development version 6.3.0.17 (2018-12-13) or later
- Version 6.3.0 will NOT work
Home Assistant 0.84.2 or later

Hass configuration - General

This page describes configuring Hass and Tasmota without MQTT device discovery, with manual configuration of each device in Hass.

While automatic discovery is the recommended method, an advantage of manually configuring device is the user maintains control of all aspects of the device configuration and usage.

Hass configuration not exposed in the UI is done by editing the file configuration.yaml which is found in folder .homeassistant after installation and first start of Hass.

Note: After every change to the configuration file you'll need to restart Hass to make it aware of the changes. This can be done either:

Through the UI: Configuration -> General -> Server Management -> Restart
From command line: On a Debian Linux based system, use the command sudo systemctl restart home-assistant.

In the examples shown the following Sonoff-Tasmota parameters are set:

MQTT_STATUS_OFF in user_config.h = OFF
MQTT_STATUS_ON in user_config.h = ON
SUB_PREFIX in user_config.h = cmnd
PUB_PREFIX in user_config.h = stat
PUB_PREFIX2 in user_config.h = tele
Mqtt = 1
MqttHost = domus1
MqttPort = 1883
Topic = sonoff
PowerRetain = 0
TelePeriod = 300

Note: If the power state needs to be persistent across Tasmota reboots set the PowerRetain to 1.

If you are using a localized version (eg. de-DE) be sure to check the correct spelling and cases for the defines:

'D_ONLINE' for 'payload_available'
'D_OFFLINE' for 'payload_not_available'
'D_ON' for 'payload_on'
'D_OFF' for 'payload_off'

Hass configuration - MQTT broker

As Sonoff-Tasmota is MQTT based you will need to configure Home Assistant to connect to an MQTT broker.

Home Assistant comes with an embedded MQTT broker which is easy to set up but you may want to opt for a separate MQTT broker instead for better stability. A popular choice for this is the open-source Eclipse Mosquitto.

Configure an external broker

To connect Hass to an external MQTT server, use Hass web UI:\

Configuration -> Integrations -> Set up a new Integration -> MQTT\

Note: Make sure to tick the "Enable discovery" option to enable MQTT device discovery.

Configure the embedded broker

# Example configuration.yaml entry
mqtt:
  password: hello

Default username for the embedded broker is homeassistant while port defaults to 1883.

Tips

Tip: Sync power state

If the MQTT broker or Hass is restarted, or there is a WiFi outage, Tasmota device state may not be synced with Home Assistant.

Use this automation to get all your devices in sync, including power state, immediately after Home Assistant is (re)started.

# Example automations.yaml entry
- alias: "Power state on HA start-up"
  trigger:
    platform: homeassistant
    event: start
  action:
    - service: mqtt.publish
      data:
        topic: "cmnd/sonoffs/state"
        payload: ""
    - service: mqtt.publish
      data:
        topic: cmnd/sonoffs/POWER
    - service: mqtt.publish
      data:
        topic: cmnd/sonoffs/POWER2
    - service: mqtt.publish
      data:
        topic: cmnd/sonoffs/POWER3

This automation posts to the default "sonoffs" group topic. Each device will send back their status message which contains relay power and light status.

Tip: View the firmware version number of a Tasmota device

Add a sensor like below in your sensor section for each Tasmota device in one card in an order that makes sense for you. Change the state_topic and availability_topic to the unique topic of each device.

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "S20_Rock"
    state_topic: "stat/S20Beta/STATUS2"
    value_template: "{{value_json['StatusFWR'].Version }}"
    qos: 0
    availability_topic: "tele/S20Beta/LWT"
    payload_available: "Online"
    payload_not_available: "Offline"

Automation to have each device to push out the firmware version on Home Assistant reboot. Tip: The user can manually trigger this automation without a reboot during upgrades of devices.

# Example automations.yaml entry
- alias: "Sonoff state on HA start-up"
  trigger:
    platform: homeassistant
    event: start
  action:
    - service: mqtt.publish
      data:
        topic: "cmnd/sonoffs/STATUS"
        payload: "2"

Tip: Get the IP address of a newly flashed Sonoff (ESP8266)

Here is some code that will display the IP address of you newly flashed ESP8266 if you have to change PROJECT name in user_config.h you must also change the script topic has to match it.

The script:

# Example scripts.yaml entry
 get_sonoff_ip:
  alias: Get Sonoff New IP (sonoff)
  sequence:
  - data:
      topic: cmnd/sonoff/ipaddress
    service: mqtt.publish

topic: cmnd/the PROJECT NAME/ipaddress

The sensor:

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "SonOff IP"
    state_topic: 'stat/sonoff/RESULT'
    value_template: "{{ value_json.IPAddress1.split(' ')[1].replace('(','').replace(')','') }}"

Put it into a group

# Example groups.yaml entry
  sonoff:
    name: "Sonoff Tasmota"
    control: hidden
    entities:
      - script.get_sonoff_ip
      - sensor.sonoff_ip

Restart HA and plug in your newly flashed ESP8266 device. Click EXECUTE (in the new group) and the "Sonoff IP" sensor will display the IP address. After finding out the new IP don't forget to change the topic name in "Configure MQTT" in the Configuration Menu.

Tip: Wi-Fi RSSI Signal Strength

Display the Wi-Fi signal strength published from each telemetry message (default time is every 300 seconds). Change the two topics below to your Tasmota device name. It may not immediately show on your Home Assistant panel until the next telemetry message is published.

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    state_topic: "tele/SNF-Washer/STATE"
    name: "Washer Signal"
    unit_of_measurement: "%"
    value_template: "{{value_json['Wifi'].RSSI }}"
    availability_topic: "tele/SNF-Washer/LWT"
    payload_available: "Online"
    payload_not_available: "Offline"

Configure Switches

Use the switch.mqtt component.

Use POWER1, POWER2, etc when you are using a device with more than one relay or if SetOption26 is enabled)

Configure the module, and on the Console run:
SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

# Example configuration.yaml entry
switch:
  - platform: mqtt
    name: "Sonoff power"
    state_topic: "stat/sonoff/RESULT"
    value_template: "{{ value_json.POWER }}"
    command_topic: "cmnd/sonoff/POWER"
    availability_topic: "tele/sonoff/LWT"
    qos: 1
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    retain: false

If you are using your Sonoff to control a light, you may want to use the light.mqtt component. Replace switch: with light: in the above configuration. All other settings remain the same.

Configure Sensors

Use the sensor.mqtt component.

DHT22 sensor

Periodical updates

A DHT22 Temperature and Humidity sensor connected to a Sonoff TH10 will send in TelePeriod set intervals the following information to the MQTT broker:

tele/sonoff/SENSOR = {"Time":"2017-02-12T16:11:12", "DHT22":{"Temperature":23.9, "Humidity":34.1}}

To make the information visible in HA add the following lines to the configuration file.

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "Tele Temperature"
    state_topic: "tele/sonoff/SENSOR"
    value_template: "{{ value_json['DHT22'].Temperature }}"
    unit_of_measurement: "°C"
    availability_topic: "tele/sonoff/LWT"
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "Tele Humidity"
    state_topic: "tele/sonoff/SENSOR"
    value_template: "{{ value_json['DHT22'].Humidity }}"
    unit_of_measurement: "%"
    availability_topic: "tele/sonoff/LWT"
    payload_available: "Online"
    payload_not_available: "Offline"

Manual updates

Another means of sensor information retrieval from Sonoff-Tasmota is using the status command Status 10 or cmnd/sonoff/status 10. This would result in a message like:

stat/sonoff/STATUS10 {"StatusSNS":{"Time":"2017-02-11T18:06:05", "DHT22":{"Temperature":"21.8", "Humidity":"48.0"}}}

The HA configuration would then look like this:

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "Stat Temperature"
    state_topic: "stat/sonoff/STATUS10"
    value_template: "{{ value_json.StatusSNS.DHT22.Temperature }}"
    unit_of_measurement: "°C"
  - platform: mqtt
    name: "Stat Humidity"
    state_topic: "stat/sonoff/STATUS10"
    value_template: "{{ value_json.StatusSNS.DHT22.Humidity }}"
    unit_of_measurement: "%"

The Sonoff-Tasmota command could be initiated by a mosquitto mqtt pub command on mosquitto_pub -h localhost -t 'cmnd/sonoff/status' -m '10'

HTU and BMP I2C sensors

HTU21 and BMP280 sensors connected to sonoff2 send messages like:

tele/sonoff2/SENSOR = {"Time":"2017-02-12T16:16:43", "HTU21":{"Temperature":24.0, "Humidity":34.0}, "BMP280":{"Temperature":24.9, "Pressure":1032.5}}

Where the Pressure information would be made available to HA with

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "Tele Pressure"
    state_topic: "tele/sonoff2/SENSOR"
    value_template: "{{ value_json.BMP280.Pressure }}"
    unit_of_measurement: "hPa"

Sonoff Pow Energy sensors

Periodical updates

A Sonoff Pow device called pow1 will periodically send the following message:

tele/pow1/SENSOR = {"Time":"2018-02-14T21:51:31","ENERGY":{"Total":0.984,"Yesterday":0.000,"Today":0.984,"Period":12,"Power":145,"Factor":0.90,"Voltage":220,"Current":0.731}}

The HA configuration for Energy, Power, Voltage and Current would be:

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "Energy"
    state_topic: "tele/pow1/SENSOR"
    value_template: '{{ value_json["ENERGY"]["Today"] }}'
    unit_of_measurement: "kWh"
  - platform: mqtt
    name: "Power"
    state_topic: "tele/pow1/SENSOR"
    value_template: '{{ value_json["ENERGY"]["Power"] }}'
    unit_of_measurement: "W"
  - platform: mqtt
    name: "Voltage"
    state_topic: "tele/pow1/SENSOR"
    value_template: '{{ value_json["ENERGY"]["Voltage"] }}'
    unit_of_measurement: "V"
  - platform: mqtt
    name: "Current"
    state_topic: "tele/pow1/SENSOR"
    value_template: '{{ value_json["ENERGY"]["Current"] }}'
    unit_of_measurement: "A"

Manual updates

The manual message retrieved with command Status 8 or cmnd/pow1/status 8 will show:

stat/pow1/STATUS8 = {"StatusPWR":{"Yesterday":0.002, "Today":0.002, "Power":4, "Factor":0.37, "Voltage":227, "Current":0.056}}

The HA configuration for Power Factor would then be:

# Example configuration.yaml entry
sensor:
  - platform: mqtt
    name: "Power Factor"
    state_topic: "stat/pow1/STATUS8"
    value_template: "{{ value_json.StatusPWR.Factor }}"

Complete tutorial on a power monitoring plug setup:

Configure Lights

Use the light.mqtt component.

Dimmer / PWM LED

Configure the module, and on the Console run:
SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

# Example configuration.yaml entry
light:
  - platform: mqtt
    name: "Light 1"
    command_topic: "cmnd/light1/POWER"
    state_topic: "tele/light1/STATE"
    state_value_template: "{{value_json.POWER}}"
    availability_topic: "tele/light1/LWT"
    brightness_command_topic: "cmnd/light1/Dimmer"
    brightness_state_topic: "tele/light1/STATE"
    brightness_scale: 100
    on_command_type: "brightness"
    brightness_value_template: "{{value_json.Dimmer}}"
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    qos: 1
    retain: false

RGB Lights

Any 3-channel PWM LED dimmer or AiLight

Configure the module, and on the Console run:
SetOption17 1 - This enables decimal colors
SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

# Example configuration.yaml entry
light:
  - platform: mqtt
    name: "Light 1"
    command_topic: "cmnd/light1/POWER"
    state_topic: "tele/light1/STATE"
    state_value_template: "{{value_json.POWER}}"
    availability_topic: "tele/light1/LWT"
    brightness_command_topic: "cmnd/light1/Dimmer"
    brightness_state_topic: "tele/light1/STATE"
    brightness_scale: 100
    on_command_type: "brightness"
    brightness_value_template: "{{value_json.Dimmer}}"
    rgb_command_topic: "cmnd/light1/Color2"
    rgb_state_topic: "tele/light1/STATE"
    rgb_value_template: "{{value_json.Color.split(',')[0:3]|join(',')}}"
    effect_command_topic: "cmnd/light1/Scheme"
    effect_state_topic: "tele/light1/STATE"
    effect_value_template: "{{value_json.Scheme}}"
    effect_list:
      - 0
      - 1
      - 2
      - 3
      - 4
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    qos: 1
    retain: false

LED WS281X

Configure any of the pins of the module as "WS2812B", and on the Console run:
SetOption17 1 - This enables decimal colors\

# Example configuration.yaml entry
light:
  - platform: mqtt
    name: "Light 1"
    command_topic: "cmnd/light1/POWER"
    state_topic: "stat/light1/STATE"
    state_value_template: "{{value_json.POWER}}"
    availability_topic: "tele/light1/LWT"
    brightness_command_topic: "cmnd/light1/Dimmer"
    brightness_state_topic: "stat/light1/STATE"
    brightness_scale: 100
    on_command_type: "brightness"
    brightness_value_template: "{{value_json.Dimmer}}"
    rgb_command_topic: "cmnd/light1/Color2"
    rgb_state_topic: "tele/light1/STATE"
    rgb_value_template: "{{value_json.Color.split(',')[0:3]|join(',')}}"
    effect_command_topic: "cmnd/light1/Scheme"
    effect_state_topic: "stat/light1/STATE"
    effect_value_template: "{{value_json.Scheme}}"
    effect_list:
      - 0
      - 1
      - 2
      - 3
      - 4
      - 5
      - 6
      - 7
      - 8
      - 9
      - 10
      - 11
      - 12
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    qos: 1
    retain: false

RGBW Lights

MagicHome LED Controller

Configure the module as "34 MagicHome", and on the Console run:
SetOption17 1 - This enables decimal colors
SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

Arilux LC02

Configure the module as "18 Generic module", and on the Console run: SetOption17 1 - This enables decimal colors SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

More info how to configure the GPIO Arilux LC02

# Example configuration.yaml entry
light:
  - platform: mqtt
    name: "Light 1"
    command_topic: "cmnd/light1/POWER"
    state_topic: "tele/light1/STATE"
    state_value_template: "{{value_json.POWER}}"
    availability_topic: "tele/light1/LWT"
    brightness_command_topic: "cmnd/light1/Dimmer"
    brightness_state_topic: "tele/light1/STATE"
    brightness_scale: 100
    on_command_type: "brightness"
    brightness_value_template: "{{value_json.Dimmer}}"
    white_value_state_topic: "tele/light1/STATE"
    white_value_command_topic: "cmnd/light1/White"
    white_value_scale: 100
    white_value_template: "{{ value_json.Channel[3] }}"
    rgb_command_topic: "cmnd/light1/Color2"
    rgb_state_topic: "tele/light1/STATE"
    rgb_value_template: "{{value_json.Color.split(',')[0:3]|join(',')}}"
    effect_command_topic: "cmnd/light1/Scheme"
    effect_state_topic: "tele/light1/STATE"
    effect_value_template: "{{value_json.Scheme}}"
    effect_list:
      - 0
      - 1
      - 2
      - 3
      - 4
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    qos: 1
    retain: false

RGBWW Lights

Sonoff B1, or any 5-channel LED dimmer

Configure the module, and on the Console run:
SetOption17 1 - This enables decimal colors
SetOption59 1 - This enables sending of tele//STATE on POWER and light related commands

You can set the following using the sonoff web interface - Console or by sending it MQTT commands

Fade on (optional, but makes the transitions slower)
Speed 5 (optional, but makes the transitions slower)

# Example configuration.yaml entry
light:
  - platform: mqtt
    name: "Light 1"
    command_topic: "cmnd/light1/POWER"
    state_topic: "tele/light1/STATE"
    state_value_template: "{{value_json.POWER}}"
    availability_topic: "tele/light1/LWT"
    brightness_command_topic: "cmnd/light1/Dimmer"
    brightness_state_topic: "tele/light1/STATE"
    brightness_scale: 100
    on_command_type: "brightness"
    brightness_value_template: "{{value_json.Dimmer}}"
    color_temp_command_topic: "cmnd/light1/CT"
    color_temp_state_topic: "tele/light1/STATE"
    color_temp_value_template: "{{value_json.CT}}"
    rgb_command_topic: "cmnd/light1/Color2"
    rgb_state_topic: "tele/light1/STATE"
    rgb_value_template: "{{value_json.Color.split(',')[0:3]|join(',')}}"
    effect_command_topic: "cmnd/light1/Scheme"
    effect_state_topic: "tele/light1/STATE"
    effect_value_template: "{{value_json.Scheme}}"
    effect_list:
      - 0
      - 1
      - 2
      - 3
      - 4
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    qos: 1
    retain: false

Configure RF Codes from Sonoff-Bridge

Use the binary_sensor.mqtt component.

# Example configuration.yaml entry
binary_sensor:
  - platform: mqtt
    name: "Test RF bridge rfkey 1"
    payload_on: "1"
    payload_off: "0"
    device_class: opening
    state_topic: "tele/sonoff_bridge/RESULT"
    value_template: '{{ value_json.RfReceived.RfKey }}'

Configure iFan02

Use the fan.mqtt component.

iFan02 - Example 1

From @kbickar in Support for Ifan02 #2839`

Modified by @finity69x2 in Support for Ifan02 #2839`

# Example configuration.yaml entry
fan:
- platform: mqtt
    name: "Sonoff Fan"
    command_topic: "cmnd/sonoff_fan/FanSpeed"
    speed_command_topic: "cmnd/sonoff_fan/FanSpeed"
    state_topic: "stat/sonoff_fan/RESULT"
    speed_state_topic: "stat/sonoff_fan/RESULT"
    #state_value_template: "{% if value_json.FanSpeed == 0 -%}0{%- elif value_json.FanSpeed > 0 -%}4{%- endif %}"
    state_value_template: >
      {% if value_json.FanSpeed is defined %}
        {% if value_json.FanSpeed == 0 -%}0{%- elif value_json.FanSpeed > 0 -%}4{%- endif %}
      {% else %}
        {% if states.fan.sonoff_fan.state == 'off' -%}0{%- elif states.fan.sonoff_fan.state == 'on' -%}4{%- endif %}
      {% endif %}
    speed_value_template: "{{ value_json.FanSpeed }}"
    availability_topic: tele/sonoff_fan/LWT
    payload_off: "0"
    payload_on: "4"
    payload_low_speed: "1"
    payload_medium_speed: "2"
    payload_high_speed: "3"
    payload_available: Online
    payload_not_available: Offline
    speeds:
      - off
      - low
      - medium
      - high

iFan02 - Example 2 - Group with Fan + Light

Combination of configs found in the support thread: Support for Ifan02 #2839 and Home Assistant forum: Sonoff IFan02 (Tasmota) MQTT Fan

# Example configuration.yaml entry
fan:
  - platform: mqtt
    name: "Pat Ceiling Fan"
    state_topic: "stat/ifan02_1/RESULT"
    speed_state_topic: "stat/ifan02_1/RESULT"
    state_value_template: >
        {% if value_json.FanSpeed is defined %}
          {% if value_json.FanSpeed == 0 -%}0{%- elif value_json.FanSpeed > 0 -%}2{%- endif %}
        {% else %}
          {% if states.fan.pat_ceiling_fan.state == 'off' -%}0{%- elif states.fan.pat_ceiling_fan.state == 'on' -%}2{%- endif %}
        {% endif %}
    speed_value_template: "{{ value_json.FanSpeed }}"
    availability_topic: tele/ifan02_1/LWT
    payload_available: Online
    payload_not_available: Offline
    speed_command_topic: "cmnd/ifan02_1/FanSpeed"
    payload_low_speed: "1"
    payload_medium_speed: "2"
    payload_high_speed: "3"
    command_topic: "cmnd/ifan02_1/FanSpeed"
    payload_off: "0"
    payload_on: "2"
    qos: 1
    retain: false
    speeds:
      - low
      - medium
      - high
light:
  - platform: mqtt
    name: "Pat Ceiling Light"
    state_topic: "tele/ifan02_1/STATE"
    value_template: "{{ value_json.POWER }}"
    command_topic: "cmnd/ifan02_1/POWER"
    availability_topic: "tele/ifan02_1/LWT"
    qos: 1
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    retain: false

groups.yaml

# Example groups.yaml entry
Pat Ceiling Fan:
  - fan.pat_ceiling_fan
  - light.pat_ceiling_light

Configure Sonoff S31 w/ Power Monitoring as group of switch + sensor

Configure the module as Sonoff S31, and on the Console run:
SetOption4 1
SetOption59 1

# Example configuration.yaml entry
switch:
  - platform: mqtt
    name: "s31_02 power"
    state_topic: "tele/s31_02/STATE"
    value_template: "{{ value_json.POWER }}"
    command_topic: "cmnd/s31_02/POWER"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_on: "ON"
    payload_off: "OFF"
    payload_available: "Online"
    payload_not_available: "Offline"
    retain: false

sensor:
  - platform: mqtt
    name: "s31_02 Voltage"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Voltage }}"
    unit_of_measurement: "V"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Current"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Current | round(2) }}"
    unit_of_measurement: "A"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Power"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Power }}"
    unit_of_measurement: "W"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Power Factor"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Factor }}"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Energy Today"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Today }}"
    unit_of_measurement: "kWh"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Energy Yesterday"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Yesterday }}"
    unit_of_measurement: "kWh"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"
  - platform: mqtt
    name: "s31_02 Energy Total"
    state_topic: "tele/s31_02/SENSOR"
    value_template: "{{ value_json['ENERGY'].Total }}"
    unit_of_measurement: "kWh"
    availability_topic: "tele/s31_02/LWT"
    qos: 1
    payload_available: "Online"
    payload_not_available: "Offline"

groups.yaml

Sonoff S31_02:
  - switch.s31_02
  - sensor.s31_02_voltage
  - sensor.s31_02_current
  - sensor.s31_02_power
  - sensor.s31_02_power_factor
  - sensor.s31_02_energy_today
  - sensor.s31_02_energy_yesterday
  - sensor.s31_02_energy_total

Counter/Pulse/Water Meter sensor

The tasmota counter is volatile (not saved in case or reset/ reboot) due to flash wear. Common use cases are a water meter that works with a pulse. this custom component counter can handle it.

- platform: tasmota_counter
    name: HASS_NAME
    s topic: TOPIC
    counter_id: 1
    max_valid_diff: 2000
    unit_of_measurement: 'l'
    icon: mdi:water-pump
    expire_after: 300
    value_template: "{{ (4885 + (value))|int }}"

Home Assistant ‐ Manual Config - seurat-atreides/Sonoff-Tasmota GitHub Wiki

Hass configuration - General

Hass configuration - MQTT broker

Configure an external broker

Configure the embedded broker

Tips

Tip: Sync power state

Tip: View the firmware version number of a Tasmota device

Tip: Get the IP address of a newly flashed Sonoff (ESP8266)

Tip: Wi-Fi RSSI Signal Strength

Configure Switches

Configure Sensors

DHT22 sensor

Periodical updates

Manual updates

HTU and BMP I2C sensors

Sonoff Pow Energy sensors

Periodical updates

Manual updates

Configure Lights

Dimmer / PWM LED

RGB Lights

Any 3-channel PWM LED dimmer or AiLight

LED WS281X

RGBW Lights

MagicHome LED Controller

Arilux LC02

RGBWW Lights

Sonoff B1, or any 5-channel LED dimmer

Configure RF Codes from Sonoff-Bridge

Configure iFan02

iFan02 - Example 1

iFan02 - Example 2 - Group with Fan + Light

Configure Sonoff S31 w/ Power Monitoring as group of switch + sensor

Counter/Pulse/Water Meter sensor

⚠️ **GitHub.com Fallback** ⚠️

⚠️ GitHub.com Fallback ⚠️
