This page describes some ways to hardening PureDarwin (and intrinsically Darwin 9). Please feel free to contribute.
"Know your enemy" - Rage Against the Machine
hard • en |ˈhärdn|
verb make or become hard or harder : [ intrans. ] wait for the glue to harden | [ trans. ]_ bricks that seem to have been hardened by firing_.
- make or become more severe and less sympathetic : [ trans. ] she hardened her heart.
- make or become tougher and more clearly defined : [ intrans. ] suspicion hardened into certainty.
- [ intrans. ] (of prices of stocks, commodities, etc.) rise and remain steady at a higher level.
WARNING! YOU HAVE BEEN WARNED! NOW HOPE YOU KNOW WHAT YOU DO! WARNING!
See above, you have been warned in red. Also, take a look at Legal page.
Assuming PureDarwin will be installed on /Volume/Puredarwin, these two variables below could be used in the following information.
export VOLUME="/Volume/PureDarwin"
export DISK=/bin/df | /usr/bin/grep "^/Volume/PureDarwin" | awk -F ' ' '{print $1}'
You can also use setenv, according to your favorite shell.
Note that the ownership of the session is root.
Securely erase freespace of a disk on $DISKSecurely erase a disk on $DISK
diskutil secureErase <level> $DISK
diskutil secureErase freespace <level> $DISK
3 levels are available in man diskutil:
- Single pass randomly erase the disk
- US DoD 7 pass secure erase
- Gutmann algorithm 35 pass secure erase
`rm' with -P option will overwrite file(s) 3 times, first with the byte pattern 0xff, then 0x00 and finally 0xff before deleting them.
Securely remove files or directories:
srm -r -m dir Same as above, 3 levels available in `man srm':
-s overwrites with a single pass of random data -m is the 7 US DoD compliant passes (0xF6, 0x00, 0xFF, random, 0x00, 0xFF, random) If neither is specified, the 35-pass Gutmann algorithm is used
Probability says pd_roots & pd_drivers may include unused packages with potential vulnerabilities.
By default, the list is big, too big:
cat pd_roots pd_drivers | wc -l 183 Knowing what you're doing, you can safely remove more than hundred packages.
hdiutil uses the DiskImages framework (FileVault encryption is supported) to manipulate disk images.
If you want to compress a folder:
hdiutil create -srcfolder "<folder>" -format UDBZ <compressed folder>.dmg srm -r <folder>
In order to mount it later, it can be attached using hdiutil:
mkdir <folder>
hdiutil attach -mountpoint <compressed folder>.dmg
EFI determines which partition or disk to load. It also determines whether the user can enter (or not) in singe-user mode. More information in efiboot, boot and the boot process pages.
Creating an EFI password disables:
- the single-user mode
- loading of unapproved partition or disk
- target disk mode at startup
"Cliché", assign a BIOS password in order to prevent potential way to access the OS by booting alternative media.
if [ "${BootType}" = "singleuser" ];then authentification.sh fi Assuming authentification.sh is a "nice" script.
According to the file itself, in the first comments:
# Note that this file is consulted directly only when the system is running # in single-user mode. At other times this information is provided by # Open Directory. Try to change the shell PATH from:
root:*:0:0:System Administrator:/var/root:/bin/sh
to:
root:*:0:0:System Administrator:/var/root:/dev/null
If you remove/disable the code portion of what activate/detect the single user mode (-s), there is no way to enter in single user mode. A patch is needed in this case (TODO).
FIXME
FIXME
SystemKeep in mind, that any binary you would like to run, can have already been compromised or can be compromised at run-time. A possible approach is to use your own trusted binary from a read-only medium (when possible), taking in account how your binary is loaded and run in memory. As an illustrative example, `netstat' is well known to be easily short-circuited in order to not show some connections (and several ways exist..).
There are plenty "oldschool" UNIX utility, for historical causes, posterity purpose or simply because there are still usefull, as some of them:
- kill, killall, netstat, ps, sysctl, top, uptime, w, who, ... We can also find specific utility to Darwin, or at least to BSD subsystems also detailled below.
sysctl {style="background-color:transparent;color:rgb(0,0,0);font-family:Arial,Verdana,sans-serif;font-size:14px;margin-top:10px;margin-right:10px;margin-bottom:10px;margin-left:0px"}
Retrieving memory status is easy:
sysctl -a | grep mem hw.physmem = 2147483648 hw.usermem = 1810808832 hw.memsize = 2147483648 hw.memsize: 2147483648
A more human readable result of the swap usage: sysctl -a | grep swap
vm.swapusage: total = 1024.00M used = 416.94M free = 607.06M
Mach kernel version: Darwin Kernel Version 9.1.0: Wed Oct 31 17:46:22 PDT 2007; root:xnu-1228.0.2~1/RELEASE_I386 Kernel configured for up to 2 processors. 2 processors are physically available. 2 processors are logically available. Processor type: i486 (Intel 80486)Processors active: 0 1 Primary memory available: 1.00 gigabytes Default processor set: 52 tasks, 211 threads, 2 processors Load average: 0.02, Mach factor: 1.96
Rudimentary command, an (different) alternative of the missing `free' UNIX utility.
Mach Virtual Memory Statistics: (page size of 4096 bytes) Pages free: 19385. Pages active: 131831. Pages inactive: 51339. Pages wired down: 58216. "Translation faults": 6266580. Pages copy-on-write: 161179. Pages zero filled: 3302531. Pages reactivated: 5342. Pageins: 167299. Pageouts: 3430. Object cache: 24703 hits of 77103 lookups (32% hit rate)
Some particular value needs to be watch, as the Pageouts number values. If it goes more than 0, it simply means that your memory is swapping which is not what you want, most of the time. Swapping can result in potential sensitive information dumped from memory to the harddisk (in the swapfile(s)). Swapping can also happen simply because not enough memory is available.
FIXME
According to the man, pmset changes and reads power management settings such as idle sleep timing, wake on administrative access, automatic restart on power loss, etc.
Changes are saved in a persistent plist file at /Library/Preferences/SystemConfiguration/com.apple.PowerManagement.plist Scheduled power on/off events are stored separately in /Library/Preferences/SystemConfiguration/com.apple.AutoWake.plist From the man: boot - tell the kernel that system boot is complete (normally LoginWindow does this). May be useful to Darwin users.
FIXME
pmset -a sleep 0 0 to set the idle time to never
pmset -a disksleep 1
pmset -a womp 0
pmset -a autorestart 0
pmset -a powerbutton 0
Use restrictive file mode as possible. Avoid file readable by anyone and writable (typically a 644) by the owner only.
chmod 600 * Idem for folders.
sudo chmod 700 /Users/<username>
Persistent effects. (FIXME NOT TESTED)
sudo defaults write /Library/Preferences/.GlobalPreferences NSUmask 77 You can also use non persistent umask command illustrated by the example just below.
aladin@niwarderup:/test% touch before_umask
aladin@niwarderup:/test% mkdir before_umask_dir
aladin@niwarderup:/test% umask 77
aladin@niwarderup:/test% touch after_umask
aladin@niwarderup:/test% mkdir after_umask_dir
aladin@niwarderup:/test% ls -l
total 0
-rw-r--r-- 1 aladin staff 0 Jun 20 19:07 before_umask
drwxr-xr-x 2 aladin staff 68 Jun 20 19:07 before_umask_dir
-rw------- 1 aladin staff 0 Jun 20 19:07 after_umask
drwx------ 2 aladin staff 68 Jun 20 19:07 after_umask_dir
Extended attributes extend the basic attributes associated with files and directories in the file system. They are stored as name:data pairs associated with file system objects (files, directories, symlinks, etc). xattr
ls -@l <file> FIXME
Set the user immutable flag (owner or super-user only):
chflags uchg filename.txt
Clear the user immutable flag (owner or super-user only):
chflags nouchg filename.txt
Executable files with this bit set will run with effective uid set to the uid of the file owner. Moreover, directories with the set-user-id bit set will force all files and sub-directories created in them to be owned by the directory owner and not by the uid of the creating process.
find / -type f -perm -04001 -ls > suid-files find / -type f -perm -02001 -ls > sgid-files find / -type f -perm -04001 -user 0 -ls > suid-root find / -type f -perm -02001 -group 0 -ls > sgid-root find / -type f -perm -02001 -group 80 -ls > sgid-admin This is a simple and effective example on Mac OS X (9.4.0) showing how suid is dangerous:
osascript -e "tell app "ARDAgent" to do shell script "whoami""
find / -type f -perm -02 -ls
find / -type d -perm -02 -ls
- All files and folders in the KEXT, including the KEXT itself, must be owned by the root user (uid 0)
- All files and folders in the KEXT, including the KEXT itself, must be owned by the wheel group (gid 0)
- All folders in the KEXT, including the KEXT itself, must have the permissions 0755 (octal)
- All files in the KEXT must have permissions 0644 (octal)
- A KEXT is not the place to store a user-space executable. /usr/sbin/chown -R root:wheel MyKEXT.kext
If the permissions differ, diskutil can repair them.
diskutil repairPermissions $PUREDARWIN
diskutil enableJournal $PUREDARWIN/
The kernel uses a pool of external swap files to support demand paging. Caution, it seems swap files aren't erased securely at startup. Swap files reside in /private/var/vm/ directory:
-rw------T 1 root wheel 67108864 Jun 22 11:51 swapfile0 -rw------T 1 root wheel 67108864 Jun 22 19:02 swapfile1
An external storage manager for dynamic pager is running as root, showing by ps aux | grep dynamic
root 26 0.0 0.1 75376 704 ?? Ss 11:50AM 0:00.01 /sbin/dynamic_pager -F /private/var/vm/swapfile
Launched with /System/Library/LaunchDaemons/com.apple.dynamic_pager.plist
Disabling swap needs caution.
Some program may require explicitly swap memory area. What happens if no more physical memory available and swap is disabled?
Non persistent way:
sudo killall dynamic_pager sudo srm /private/var/vm/swapfile*
Persistent way: Edit /System/Library/LaunchDaemons/com.apple.dynamic_pager.plist and remove the nodes: <string>/sbin/dynamic_pager</string> <string>-F</string> <string>/private/var/vm/swapfile</string>
Alternatively, the Disabled <boolean> optional key is used to disable (or not) the job. Then wipe free space.
PureDarwin, if it is not yet the case, will provide by default an encrypted swap partition. The `dynamic_pager' daemon have an option to enable encryption:
Not sure if it is still working but.. try to put ENCRYPTSWAP=-YES- in /etc/hostconfig or add the the respective launchd plist the corresponding arg.
Notes: Notice another mysterious option: -P This option is currently unimplemented. Although in the short getopt:
dynamic_pager: illegal option -- h
usage: dynamic_pager [-F filename] [-L low water alert trigger] [-H high water alert trigger] [-S file size] [-P priority]
hdiutil create -encryption AES-256 -stdinpass -srcfolder <folder> <encrypted folder>.dmg
hdiutil attach -stdinpass <encrypted folder>.dmg
256-bit and 128-bit AES keys support.
Bad, filevault key are protected by user/password. FIXME
FIXME
Some scripts as pd_adduser' or pd_injectuser', or the more regular dscl' and passwd' binaries can be used in order to create and manage user accounts. See Download page and User management page.
Boot into single user mode. Replace username with the targeted user and password with the desired password, then:
fsck -fy mount -uw / launchctl load /System/Library/LaunchDaemons/com.apple.DirectoryServices.plist dscl . -passwd /Users/username [password] Then reboot, or relaunch DirectoryServices.
Note that you can also use pd_injectuser to recreate a user account, including his password.
/usr/local/sbin/pd_injectuser
dsenableroot -d -u username -p userpassword
dsenableroot -u username -p userpassword -r rootpassword
Edit /etc/sudoers and limit the use of sudo to a single command per auth by adding:
Defaults timestamp_timeout=0
Edit /etc/sudoers in order to restrict who can run sudo by removing:
%admin ALL=(ALL) ALL and add for each <user>:
<user> ALL=(ALL) ALL
sudo fsaclctl –p / -e
sudo fsaclctl –p / -d
Read access:
chmod +a "<user> allow read" <file>
Allow write access:
chmod +a "<group> allow write" <file>
Deny write access specifically:
chmod +a "<user> deny write" <file>
ls -le <file>
FIXME A kernel-enforced access control, applied at the system call of XNU. Flexible policies?
Compiled from Scheme (LISP inside ;)) programs/rules in /usr/share/sandbox. Rules support from SYSV IPC to BSD sysctl via signals. FIXME
Look /etc/periodic/* FIXME
Edit /etc/syslog.conf.
To log authentication error messages (also the remote ones) in /var/log/secure.log, change the line
authpriv.*;remoteauth.crit /var/log/secure.log
to
authpriv.*;remoteauth.err;auth.err /var/log/secure.log
Enable facility of LOG_SECURITY:
/usr/sbin/sysctl -w net.inet.ip.fw.verbose=1
Add logamount <number> after the log keyword Setting <number> to 0 removes limit.
FIXME /etc/newsyslog.conf configuration can sets
- log file rotation based on size, last rotation time, or time of day
- secure permissions to log files at rotation time
Local logging is not really reliable if the computer is compromised, local files can be modified, removed or short-circuited
Open /etc/syslog.conf to enable remote logging. Add to the top:
. @<remote log server address or host>
Restart `syslogd' with a hangup signal (or via launchctl):
sudo killall –HUP syslogd
Edit /etc/syslog.conf and add /var/log/secure.log and /var/system.log to the host <host>:
authpriv.;remoteauth.err;auth.err @<host> .notice;authpriv,remoteauth,ftp,install.none;kern.debug;mail.crit @<host> FIXME
FIXME Logs all commands executed by all users.
To enable process accounting, create /var/account folder.
sudo mkdir -p /var/account
Create /var/account/acct to store process accounting information:
sudo touch /var/account/acct chown -R root:admin /var/account chmod -R 660 /var/account
Start accounting on the system:
sudo accton /var/account /acct
It is launched at boot.
Use lastcommto get information on previously executed commands.
FIXME Open /etc/hostconfig and add:
AUDIT=-YES-
Restart.
audit -n rotates the current log file. audit -s rotates the current log file and forces to reload settings from the audit_control file
The file /var/run/utmp stores information about the currently logged-in user, whereas /var/log/wtmp tracks all user logins/logouts, shutdowns, reboots, and crashes. Deprecated but sometimes usefull.
FIXME /var/log/cups /var/log/ftp.log /var/log/httpd /var/log/lastlog /var/log/wtmp /var/log/lookupd.log /var/log/lpr.log /var/log/secure.log /var/log/system.log /var/log/ipfw.log /var/log/fsck_hfs.log
/var/run/utmp
Library/Logs/
FIXME
FIXME Leaked memory identification and other unreferenced malloc buffers.
FIXME List all the malloc-allocated buffers in the process's heap.
FIXME malloc_history inspects a given process and lists the malloc allocations performed by it.
FIXME
FIXME To prevent the kernel from creating core dumps:
kern.coredump=0 in /etc/sysctl.conf
The non persistent way:
sysctl -w kern.coredump=0
Enable core dumps by adding the line limit core unlimited in /etc/launchd.conf (persistent way).
The resulted dump(s) will be stored in /cores folder:
file /cores/core.57 /cores/core.57: Mach-O core i386
Or from a shell (non persistent): ulimit -c unlimited Notes: kill -ABRT <pid> could be used in order to generate a core dump. On Darwin8, change the line "COREDUMPS=-NO-" in /etc/hostconfig to "COREDUMPS=-YES-"
FIXME To send all launchd logs to a file, add in /etc/syslog.conf:
launchd.* /var/log/launchd.log
Restart syslogd:
sudo kill -HUP cat /var/run/syslog.pid
To increase the level of debugging:
sudo launchctl log level debug Password: ********
FIXME See launchd page.
sudo dscl . create /dsRecTypeStandard:Config/lookupd Debug YES sudo dscl . create /dsRecTypeStandard:Config/lookupd Trace YES
Edit /etc/syslog.conf and replace netinfo.err by netinfo.debug
Restart daemons
sudo kill -HUP cat /var/run/syslog.pid
sudo kill -HUP cat /var/run/lookupd.pid
sudo dscl . delete /dsRecTypeStandard:Config/lookupd
Edit /etc/syslog.conf and replace netinfo.debug with netinfo.err
Restart daemons
sudo kill -HUP cat /var/run/syslog.pid
sudo kill -HUP `cat /var/run/lookupd.pid
FIXME Open /System/Library/LaunchDaemons/com.apple.diskarbitrationd.plist:
<key>ProgramArguments</key> <array> <string>/usr/sbin/diskarbitrationd</string> </array>
and simply append "-d":
<key>ProgramArguments</key> <array> <string>/usr/sbin/diskarbitrationd -d</string> </array> FIXME
fs_usage reports system calls and page faults related to filesystem activity in real-time, often usefull for debugging.
Remember by default (without any options), fs_usage itself, Terminal, telnetd, sshd, rlogind, tcsh, csh and sh processes are excluded from the output.
Identify files used by an application at launchtime:
sudo fs_usage -w | grep <application>
-w options forces wider, detailed, output.
FIXME
DTrace {style="margin-top:10px;margin-bottom:10px;color:rgb(0,0,0);margin-left:10px;margin-right:0px"}
The generic front-end to the DTrace facility is a powerfull dynamic debugger and analysis tool. See the DTrace page.
FIXME See The XNU kernel page.
kernel-tools sysutils/kernel-tools 8J2135 Tools required to build xnu for Intel gcc_select sysutils/gcc_select 0.1 Switch the default compiler After kernel-tools installed, the compilation will fail irremediably with some tool not found in /usr/local/bin/. A quick fix with symbolic links: /usr/local/bin/check_dylib->/opt/local/bin/check_dylib /usr/local/bin/checksyms->/opt/local/bin/checksyms /usr/local/bin/cmpshlib->/opt/local/bin/cmpshlib /usr/local/bin/decomment->/opt/local/bin/decomment /usr/local/bin/hack_libgcc->/opt/local/bin/hack_libgcc /usr/local/bin/indr->/opt/local/bin/indr /usr/local/bin/kern_tool->/opt/local/bin/kern_tool /usr/local/bin/kextsymboltool->/opt/local/bin/kextsymboltool /usr/local/bin/mkshlib->/opt/local/bin/mkshlib /usr/local/bin/seg_addr_table->/opt/local/bin/seg_addr_table /usr/local/bin/seg_hack->/opt/local/bin/seg_hack /usr/local/bin/relpath->/opt/local/bin/relpath
FIXME bsd/conf/MASTER iokit/conf/MASTER.i386 libsa/conf/MASTER osfmk/conf/MASTER.i386 security/conf/MASTER bsd/conf/MASTER.i386 libkern/conf/MASTER libsa/conf/MASTER.i386 pexpert/conf/MASTER security/conf/MASTER.i386 iokit/conf/MASTER libkern/conf/MASTER.i386 osfmk/conf/MASTER pexpert/conf/MASTER.i386
Note we don't use MASTER.ppc files although they are still existing.
FIXME ProductName: Mac OS X ProductVersion: 10.5.4 BuildVersion: 9E17
gcc version: Using built-in specs. Target: i686-apple-darwin9 Configured with: /var/tmp/gcc/gcc-5465~16/src/configure --disable-checking -enable-werror --prefix=/usr --mandir=/share/man --enable-languages=c,objc,c++,obj-c++ --program-transform-name=/^[cg][^.-]*$/s/$/-4.0/ --with-gxx-include-dir=/include/c++/4.0.0 --with-slibdir=/usr/lib --build=i686-apple-darwin9 --with-arch=apple --with-tune=generic --host=i686-apple-darwin9 --target=i686-apple-darwin9 Thread model: posix gcc version 4.0.1 (Apple Inc. build 5465)
FIXME make KERNEL_CONFIGS="RELEASE" all VERBOSE=YES FIXME
FIXME
This is not yet implemented nor investigated. Some security concepts "à la OpenBSD" could be reused into Darwin, at least partially. Security levels well known in OpenBSD “world� is going to be partially (and step by step) introduced and reused into PureDarwin. According to OpenBSD website, “Security levels essentially set how the kernel will handle system security�. In OpenBSD, there are four security levels, from the less to the most secure level: -1, 0, 1, 2 In PureDarwin, nyi.
In OpenBSD, securelevels are set from /etc/rc.securelevel In PureDarwin, nyi. securelevels are set from [unknown location/securelevel.plist]
In OpenBSD, the end of the boot process is showing which security level is used. In PureDarwin, nyi.
In OpenBSD, sysctl kern.securelevel=x can be used to adjust "on live" the security level. In order to adjust from a higher security level to a lower security level, a reboot is needed. In PureDarwin, `sysctl' is reporting the option (but not yet tested)
kern.securelevel = 0 kern.securelevel: 0 kern.secure_kernel: 0
In OpenBSD, securelevel -1: no additional kernel security features, nor restrictive permission. Not for production use.
In OpenBSD, securelevel 0: used at first boot. If securelevel 1 is set, it will be used after the boot process finish. There are no added features of securelevel 0. In PureDarwin, ?
In OpenBSD, securelevel 1: /dev/mem and /dev/kmem cannot be write. Raw disk are read-only. etc...
In OpenBSD, securelevel 2: ...
FIXME. Take care of MACH_DEBUG. According to osfmk/conf/MASTER configuration file: # MACH_DEBUG enables the mach_debug_server, a message interface used to # retrieve or control various statistics. This interface may expose data # structures that would not normally be allowed outside the kernel, and # MUST NOT be enabled on a released configuration. options MACH_DEBUG # # options MACH_IPC_DEBUG # # # options MACH_VM_DEBUG # # <debug> FIXME
FIXME /etc/authorization
networksetup -setv6off $iface
Use a restrictive netmask.
Several ways exist to detect promiscuous mode (potential running sniffer), you can use DTrace, simply parse `ifconfig' or even run a sniffer. Without promisc mode, ifconfig looks like /sbin/ifconfig en0 en0: flags=8863<UP,BROADCAST,SMART,RUNNING,SIMPLEX,MULTICAST> mtu 1500 ether 00:19:::: media: autoselect status: inactive supported media: autoselect 10baseT/UTP <half-duplex> 10baseT/UTP <full-duplex> 10baseT/UTP <full-duplex,hw-loopback> 10baseT/UTP <full-duplex,flow-control> 100baseTX <half-duplex> 100baseTX <full-duplex> 100baseTX <full-duplex,hw-loopback> 100baseTX <full-duplex,flow-control> 1000baseT <full-duplex> 1000baseT <full-duplex,hw-loopback> 1000baseT <full-duplex,flow-control> none
With promisc mode activated:
/sbin/ifconfig en0 en0: flags=8963<UP,BROADCAST,SMART,RUNNING,PROMISC,SIMPLEX,MULTICAST> mtu 1500 ether 00:19:::: media: autoselect status: inactive supported media: autoselect 10baseT/UTP <half-duplex> 10baseT/UTP <full-duplex> 10baseT/UTP <full-duplex,hw-loopback> 10baseT/UTP <full-duplex,flow-control> 100baseTX <half-duplex> 100baseTX <full-duplex> 100baseTX <full-duplex,hw-loopback> 100baseTX <full-duplex,flow-control> 1000baseT <full-duplex> 1000baseT <full-duplex,hw-loopback> 1000baseT <full-duplex,flow-control> none
Be carefull with netstat, it is not so hard to compromise "its results".
netstat -anp tcp netstat -anp udp
lsof -i tcp lsof -i udp
The default rule is not really restrictive:
#ipfw list 65535 allow ip from any to any
Same for the IPv6 network stack, the default rules list looks like:
ip6fw list 33300 deny ipv6-icmp from any to any in icmptype 128 65535 allow ipv6 from any to any
If the bandwidth used can be known (estimation at least; if the use is "constant" it is really efficient) in advance, allocating only the requested amount will not let enough "space" (bandwidth) available for an intruder.
As an example, create a pipe that only allows up to 42KB/s to go through.
sudo ipfw pipe 1 cgonfi bw 42KByte/s
Attach that pipe to the outgoing traffic on port 22, effectively limiting the outgoing traffic of sshd.
Remove the pipe from the port.
Enable the firewall (default): sysctl -w net.inet.ip.fw.enable=0
Disables the firewall: sysctl -w net.inet.ip.fw.enable=1
More info:
interface en0 same_ports yes use_sockets yes unregistered_only yes
Add dynamic yes if you have a dynamic IP. Add log_denied no if you want to log packets blocked by the NAT device
Configure internal interface en0 with a private address (i.e: 192.168.1.1)
Enable IP forwarding in the kernel, it's needed. Non persistent way:
sysctl -w net.inet.ip.forwarding=1
Persistent way, in /etc/hostconfig, add or change the value to IPFORWARDING=-YES-
Route packets from the internal network to the external one via en0:
ipfw add divert natd ip from any to any via en0
Launch natd:
/usr/sbin/natd -f /etc/natd.conf
IP address: 192.168.1.* (obviously 192.168.1.1 is reserved) Subnet mask: 255.255.254.0 Gateway/default router: 192.168.1.1 DNS servers: same as the router (but not necessarily)
In /etc/hostconfig, add or change the line to DNSSERVER=-YES-
FIXME By default, all local user can access to http://127.0.0.1:631 (a web admin front-end).
sudo launchctl load -w /System/Library/LaunchDaemons/org.cups.cupsd.plist
sudo launchctl unload -w /System/Library/LaunchDaemons/org.cups.cupsd.plist FIXME
launctl unload -w /System/Library/LaunchDaemons/ftp.plist
launctl load -w /System/Library/LaunchDaemons/ftp.plist
defaults delete /Library/Preferences/SystemConfiguration/com.apple.smb.server EnabledServices
launctl unload -w /System/Library/LaunchDaemons/nmbd.plist launctl unload -w /System/Library/LaunchDaemons/smbd.plist
### ntp FIXME /etc/ntp.conf ### NFS FIXME #### Disable NFS launchctl unload -w /System/Library/LaunchDaemons/com.apple.portmap.plist launchctl unload -w /System/Library/LaunchDaemons/org.postfix.master.plistlaunctl unload -w /System/Library/LaunchDaemons/com.apple.AppleFileServer.plist
launchctl load -w /System/Library/LaunchDaemons/com.apple.portmap.plist launchctl load -w /System/Library/LaunchDaemons/org.postfix.master.plist
FIXME
sudo launchctl load -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist
sudo launchctl load -w /System/Library/LaunchDaemons/com.apple.mDNSResponder.plist
No spaces or non-DNS characters allowed for <hostname>
scutil --set LocalHostName <hostname>
...
FIXME There are so many tutorials available about how to configure and/or secure sshd that we do not need to explain these points.
Prints fingerprint of the server’s RSA key:
ssh-keygen -l -f /private/etc/ssh_host_rsa_key.pub
FIXME
FIXME
FIXME Edit /private/etc/sshd_config
Change PasswordAuthentication yes to PasswordAuthentication no Change RSAAuthentication yes to RSAAuthentication no if key-based authentication is used
FIXME
From the man:
The following example tunnels an IRC session from client machine 127.0.0.1'' (localhost) to remote server</span></span> <span style="font-family:courier new,monospace"><span style="font-size:small"> server.example.com'':
$ ssh -f -L 1234:localhost:6667 server.example.com sleep 10
$ irc -c '#users' -p 1234 pinky 127.0.0.1
You can safely remove it if you don't plan to use wireless network interface: sudo srm -Rf /System/Library/Extensions/AppleAirPort.kext sudo touch /System/Library/Extensions
No driver available at this time or reported to work, although the operation should be similar as below.
Prevent someone to reach your computer bluetooth: sudo srm -Rf /System/Library/Extensions/IOBluetoothFamily.kext sudo srm -Rf /System/Library/Extensions/IOBluetoothHIDDriver.kext sudo touch /System/Library/Extensions
No driver available at this time or reported to work, although the operation should be similar as below.
sudo srm -Rf /System/Library/Extensions/AppleOnboardAudio.kext sudo srm -Rf /System/Library/Extensions/AppleUSBAudio.kext sudo srm -Rf /System/Library/Extensions/AudioDeviceTreeUpdater.kext sudo srm -Rf /System/Library/Extensions/IOAudioFamily.kext sudo srm -Rf /System/Library/Extensions/VirtualAudioDriver.kext sudo touch /System/Library/Extensions
No driver available at this time or reported to work, although the operation should be similar as below. Prevent someone trying to watch your webcam: sudo srm -rf /System/Library/Extensions/Apple_iSight.kext sudo srm -rf /System/Library/Extensions/IOUSBFamily.kext/Contents/PlugIns/AppleUSBVideoSupport.kext sudo touch /System/Library/Extensions
Warning: Since we boot on USB we shouldn't remove this one. You probably can safely remove this one if you boot on firewire, cdrom, in a vm or other medium:
sudo srm -rf /System/Library/Extensions/IOUSBMassStorageClass.kext sudo touch /System/Library/Extensions
Except if you boot on firewire or simply need it, you could safely remove this one:
sudo srm -rf /System/Library/Extensions/IOFireWireSerialBusProtocolTransport.kext sudo touch /System/Library/Extensions
The I/O Kit registry is an abstraction layer of some logical and physical information. We can use it to retrieve some unique identifiers. Write somewhere (away from your computer) as serials you will find as possible:
ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/IOPlatformSerialNumber/ {print $4}' Q723****** ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/product-name/ {print $4}' MacBook2,1 ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/board-id/ {print $4}' Mac-F420**** ioreg -c "IOPlatformExpertDevice" | awk -F '"' '/IOPlatformUUID/ {print $4}' 00000000-0000-00-00-0019E33 ioreg -c "ATADeviceNub" | awk -F '"' '/device serial/ {print $4}' K0075****** ioreg -c "AppleAHCIDiskDriver" | awk -F '"' '/Serial Number/ {print $4}' K439T7******
ioreg -l | grep -i 'serial number' | | | | "Serial Number" = " K439********"
ioreg -l | grep -i 'serialnumber' | "IOPlatformSerialNumber" = "WQ7********"
| | "BatterySerialNumber" = "DP-ASM****-3***-3***" | | "SerialNumber" = 12***
ioreg -l | grep -i 'serial-number' | "serial-number" = <5940000000000000000000057513*******94100000000000000000000000000000000000000>
ioreg -l | grep -i 'device serial' | | | | | "device serial" = "K0075S***** "
ioreg -l -w0 -p IODeviceTree | grep device-prop | | "device-properties" = <ef0900000100000002000000280900002700000002010c00d.....
Backup and checksumUsefull behaviors.
This list is not exhaustive and this page is not about a complete guide on "how to backup well"; depending your tastes and tool availability, there are several ways to achieve correct backuping and many tools:
- ditto
- dump/restore
- pax
- rsync
- scp
- tar For more information, take a look at http://developer.apple.com/macosx/backuponmacosx.html.
We use internally a checksum list for binary roots and binary drivers intregrity (not for security purpose). The DarwinBuild project and the MacPorts project also maintain and check integrity of their sources and binaries. Paranoid: Strong Fingerprints must be trusted and encrypted or stored in an encrypted disk image.
Try to avoid for historic security purposes, collisions are easy to create.
Collisions can be created but it's "ok" for literal integrity purpose (not for fingerprint security purpose).
/usr/bin/openssl sha1 mach_kernel SHA1(BuildRoot/mach_kernel)= 19cecd3bd87c10bc4e2c167188a299a40c10d199
Paranoid: Best is to use a concatenation of several strong checksums.
FIXME dyld can:
- Dynamically link new libraries into memory
- Recover base addresses for existing libraries Library offsets are not randomized between
- invocations of the same program
- invocations of different programs but seems to not be the same from different leopard install.
FIXME
mdutil -E -i off $PUREDARWIN
Choose value between available choices:
sysctl -w net.inet.tcp.blackhole=[0 | 1 | 2] sysctl -w net.inet.udp.blackhole=[0 | 1] It doesnt seem to have any effect.
bro prelude Found in MacPorts SourceFire/Snort (MP) chkrootkit (MP) nmap (MP) rkhunter (?) tripwire (MP) etc..
Initial version on MMVIII VI VIII 2008/06/08
The goal of this project is to make Darwin more usable by providing an installation ISO, documentation, and add-on software. You are welcome to join #puredarwin on irc.freenode.net or the Gitter chat if you would like to join PureDarwin development and to add to this site.
The Wiki pages were recently moved from Google Sites and in the conversion process some formatting was lost. Please help fixing the markdown of this page by editing it. But please delete nothing, especially not (broken) images; fix them instead (see the main page of the Wiki for an example).
