RC-5 Data Logger

This data logger is mainly used for temperature recording during storage and ocean/air/highway transportation of foodstuff, medicine, chemicals and other products, especially widely used in all kinds of warehousing, logistics and cold chain, such as refrigerated containers, refrigerated trucks refrigerated package, cold storage, laboratory, etc. or in large-sized global supply chain businesses.

It has a large permanent data memory of 32000 points and comes with data management software for easy data download to computers through USB interface. With the software, you could analyze data in form of tables and graphs and export in picture format. The data can be exported in Word/Excel/text/PDF format.

Features:

1. Wide measuring range, high accuracy and large permanent data memory.
2. Data management software included for working with PC easily.
3. Data can be downloaded, analyzed, exported and printed conveniently.
4. Over Temperature Alarm & Upper/Lower Limits can be set.
5. MAX/MIN values available.

Specifications:

1. Temperature measuring range -30 °C~+70 °C; Resolution 0.1 °C
2. Accuracy ±0.5 °C(-20°C~+40°C); others, +1 °C
3. Temperature unit °C or °F optional
4. Record capacity 32000 points (MAX)
5. Record interval 10s~24 hours adjustable
6. Sensor Internal NTC thermal resistor
7. Communication interface USB
8. Waterproof grade is IP67
9. Power supply CR2032 battery(included) or power supply via USB interface, and it could upload data even if the battery is out of use.
10. Battery life in normal temperature, if the record interval sets as 15 minutes, it could be used above one year.
11. Item Size approx. 80 (L) x 34 (W) x 14 (H) mm
12. Item Weight approx. 30 g

Manual-pdf_1 Manual-pdf_2

Get the software here:

Choose the download for your platform. I have only tried the windows version. See the youtube videos below for instructions on how to use it.
