Padding - AppDaddy-Software-Solutions-Inc/framework-markup-language GitHub Wiki

Overview

The PADDING widget is used as a positioning tool to create an offset between itself and its parent/siblings.

Table of Contents

Usage

To create space around or within widgets and reduce crowding

Ideals:

  • PADDING is really useful to add more whitespace where widgets are crowded
  • PADDING should be used to fine tune layouts and is supplemental to the more structured layout widgets

Restrictions:

  • Wrapping multiple children will layout within a COLUMN and pad around that column.

Attributes :: VisibleWidget (inherited attributes)

Name Type Default Description Req
all int null The padding created on all sides of the widgets child.
left int null The padded space created on the left of the widget.
right int null The padded space created on the right of the widget.
top int null The padded space created on the top of the widget.
bottom int null The padded space created on the bottom of the widget.

Examples

<FML>
    <CENTER>
        <BOX color="amber" expand="false">
            <PADDING left="10" right="40" top="20" bottom="80">
                <BOX color="black" width="400" height="400" />
            </PADDING>
        </BOX>
    </CENTER>
</FML>

Example

logo See it in Action

Other Widgets You May Find Useful:

Framework Markup Language is an open source programming language created by AppDaddy Software Solutions Inc. FML and is licensed under a fair source license agreement and is maintained by a community of developers.
