Apache spark Partitions - vaquarkhan/Apache-Kafka-poc-and-notes GitHub Wiki

Properties of Partitions:

  • Partitions never span multiple machines i.e., tuples in the same partition are guaranteed to be on same machine.

  • Each machine in the cluster contain one or more partitions

  • The number of partitions to use is configurable .By default , it equals the total number of cores on all executor nodes.

**Default no of partitions **

Example if Machine have 4 core and 6 worker node means default no of partitions is 4*6 =24

Partitioning is possible only on pair RDD as partition working only key.

      case class CFFPurchase(customerId:Int,destination:String,price:Double)

      val purchases =List(CFFPurchase(100,"Geneva",22.25),
                CFFPurchase(300,"Zurich",42.25),
                CFFPurchase(100,"Firebourg",12.40),
                CFFPurchase(200,"st.Fallen",8.20),
                CFFPurchase(100,"Lucerne",31.80),
                CFFPurchase(300,"Basel",16.20))

     val purchasesRDD =sc.parallelize(purchases,3)

     val purchesePerMonth= purchasesRDD.map(p=>(p.customerId,(1,p.price))).reduceByKey((v1,v2)=>
    (v1._1+v2._1,v1._2+v2._2)).collect()

Hash partitioning :

Hash partitioning distribute data as er hashcode equlaay distributed. p=k.hashCode() % numPartitions

Then , all tuples in the same partition p are sent to the achin hosting p

Range Partitioning :

  1. an ordering of keys
  2. a set of sorted ranges of key

Note : tuples with keys in the same range apper on the same machine

Example -how to choose partition

8, 96, 240,400,101,800

patition 4

hashCode() n.hashCode()==n)

p=k.hashCode % numPartition

k%4

  • Partition 0: [8,96,240,400,800]
  • Partition 1: [401]
  • Partition 2:
  • Partition 3:

The results is a very ubalanced distribution which hurts performance.

Now Range Partition

Assumptions: (a) keys non negative , (b) 800 is biggest key in the RDD

Set of ranges :[1,200],[201,400],[401,600],[601,800]

  • Partition 0 : [8,96]
  • Partition 1: [240,400]
  • Partition 2:[401]
  • Partition 3:[800]

The resuts of partioning is much more balance
