Add your user templates in the appropriate section, please resize images to 150px maximum width and 100px maximum height.

No referral links allowed!!!

Plugs/sockets

Device name Device image Template
AVATAR/AISIRER Smart Plug 10A AVATAR Smart Plug {"NAME":"AWP07L","GPIO":[56,255,255,255,255,134,255,255,130,17,132,21,255],"FLAG":1,"BASE":18}
RGB Smart Plug 16A RGB Smart Plug {"NAME":"RGB Smart Plug","GPIO":[37,0,39,0,38,134,0,0,131,17,132,21,0],"FLAG":0,"BASE":45}
Panamalar NX-SM200 16A Plug Panamalar NX-SM200 {"NAME":"NX-SM200","GPIO":[0,255,0,255,56,134,0,0,131,17,132,21,0],"FLAG":0,"BASE":45}
SP201 Based Dual Plugs SP-201 Based Dual Plugs {"NAME":"SP-201","GPIO":[31,0,0,131,17,134,0,0,21,18,132,22,0],"FLAG":0,"BASE":45}
TECKIN SM-110 - UK Power monitoring plug TECKIN UK Plug {"NAME":"SM-110","GPIO":[57,255,56,255,0,134,0,0,131,17,132,21,0],"FLAG":0,"BASE":45}
WAZA Smart Plug 10A WAZA Smart Plug {"NAME":"WAZA","GPIO":[0,0,0,0,21,17,0,0,56,0,0,0,0],"FLAG":1,"BASE":18}
Tuya Esicoo Smart Plug 10A Model YX-WS01 Tuya Esicoo Smart Plug 10A Model YX-WS01 {"NAME":"Esicoo Plug","GPIO":[255,17,255,255,255,255,255,255,255,56,21,255,255],"FLAG":0,"BASE":18}
DWFeng Mini Smart Socket 10A Model AWP02L-N DWFeng Mini Smart Socket 10A Model: AWP02L-N {"NAME":"AWP02L-N","GPIO":[255,255,56,255,255,255,255,255,255,17,255,21,255],"FLAG":0,"BASE":18}

Power Strips

Device name Device image Template
Viflykoo 3 socket + USB Wifi power strip (Nocovy0428wifide3) {"NAME":"Viflykoo 3xStr","GPIO":[0,0,53,0,0,23,0,0,21,56,17,24,22],"FLAG":1,"BASE":18}

Button controls single relay only. To switch other relays.
rule on button1#state do backlog POWER1 toggle; POWER2 toggle; POWER3 toggle; POWER4 toggle endon
Geekbes 4 socket + USB Wifi power strip (B078W23BW9) {"NAME":"Geekbes 4xStri","GPIO":[0,56,0,17,22,21,0,0,23,24,25,0,0],"FLAG":1,"BASE":18}

Button controls single relay only. To switch other relays:
rule on button1#state do backlog POWER1 toggle; POWER2 toggle; POWER3 toggle; POWER4 toggle; POWER5 toggle endon

Lights/LED controllers

Device name Device image Template
Merkury A19 60W Dimmable White Bulb MI-BW902-999W {"NAME":"MI-BW902-999W","GPIO":[0,0,0,0,0,37,0,0,0,0,0,0,0],"FLAG":0,"BASE":18}
Merkury A21 75W RGBW Bulb MI-BW904-999W {"NAME":"MI-BW904-999W","GPIO":[0,0,0,0,140,37,0,0,0,142,141,0,0],"FLAG":1,"BASE":69}
Merkury BR30 65W Tunable White Bulb MI-BW905-999W {"NAME":"MI-BW905-999W","GPIO":[0,0,0,0,37,37,0,0,38,0,0,0,0],"FLAG":0,"BASE":18}
Electrodragon ESP LED Strip Board ESP LED Strip {"NAME":"ED LedStrip","GPIO":[0,0,0,0,0,0,0,0,39,38,0,37,0],"FLAG":1,"BASE":18}
Feit Electric RGBW Bulb (note BGR color order) OM60/RGBW/CA/AG {"NAME":"OM60/RGBW","GPIO":[255,255,255,255,140,37,0,0,38,142,141,255,255],"FLAG":0,"BASE":18}
Feit Electric WiFi LED Dimmable 65W Equivalent Soft White (2700K) Light BR30/927CA/AG {"NAME":"Feit BR30 WW","GPIO":[0,0,0,0,0,37,0,0,0,0,0,0,0],"FLAG":0,"BASE":18}
Feit Electric WiFi LED Dimmable 65W Equivalent Daylight (10K) Light BR30/950CA/AG {"NAME":"Feit BR30 CW","GPIO":[0,0,0,0,0,37,0,0,0,0,0,0,0],"FLAG":0,"BASE":18}

Switches/Dimmers

Device name Device image Template
Martin Jerry 15A Switch - US 1 Gang Martin Jerry 15A Switch - US 1 Gang {"NAME":"MJ Switch","GPIO":[255,255,255,255,57,56,255,255,21,17,255,255,255],"FLAG":0,"BASE":18}

Miscellaneous

Device name Device image Template
WL-SW01_10 {"NAME":"WL-SW01_10","GPIO":[17,149,0,148,0,0,0,0,21,56,0,0,0],"FLAG":0,"BASE":1}
