Uncovered Test Cases Report — Modernized Screen

The Uncovered Test Cases report (ASIDE → Reports → Test Cases without Requirements Assignment) lists all test cases in the test project that have no requirement assigned (no row in req_coverage), one row per test case, grouped by test suite. It replaces the legacy 1.9.20 lib/results/uncoveredTestCases.php HTML view with a modern Dashio-styled page backed by a plain-PHP REST BFF. This closes the last report screen that had no modernized equivalent.

Path: ASIDE menu → Reports → Test Cases without Requirements Assignment (shown only when the project has requirements enabled and a test plan is selected) URL: gui/templates/results/uncoveredTestCases.html?tproject_id=<id> BFF API: api/reports/index.php — GET ?action=uncovered_testcases&tproject_id=N Rights: testplan_metrics Tracking issue: #843

---

Table of Contents

1. Screen Layout
2. Data Flow and Parity
3. i18n
4. Permission Path and Empty States
5. BFF API Reference
6. Files

---

1. Screen Layout

Section	Description
Header	Teal Dashio header "Test Cases without Requirements Assignment — for test project X" with locale switcher
Toolbar	Dark bar: test project context, test-case count badge
Report	DataTable with columns: Test Suite, Test Case (external ID + name), grouped by suite
Empty state	Info/check icon with a localized message (no req spec / no requirements / all covered)
Footer	Elapsed time

Normal (data) state

No-requirements state

2. Data Flow and Parity

The BFF mirrors the legacy lib/results/uncoveredTestCases.php SQL step by step:

1. testproject::genComboReqSpec($tprojectId) — are any requirement specs defined? No → has_reqspec=false → "There are no Requirement Spec. defined".
2. requirement_spec_mgr::get_requirements_count() per spec — does any spec hold requirements? No → has_requirements=false → "There are no Requirements defined".
3. testproject::get_all_testcases_id($tprojectId) — all test case ids in the project, then a LEFT OUTER JOIN to req_coverage WHERE req_id IS NULL → test cases with no assigned requirement.
4. External ids joined from tcversions (via the tcversion node), full external id built as prefix + glue + tc_external_id (getTestCasePrefix), matching legacy.
5. Grouped by test suite (suite name → its test cases), sorted by suite id (legacy gen_spec_view ordering). No rows → has_data=false → "All Test Cases are covered".

Note (latent bug fixed): get_all_testcases_id($tprojectId, $tcasesID) with the default just_id mode returns a plain list of ids, not a map — so the BFF builds the IN (...) clause with implode(',', array_map('intval', (array)$tcasesID)), not array_keys().

3. i18n

9 unc.* keys in all 10 locale bundles (en de es fr it ja pt ro ru zh):

Key	English
unc.header	Test Cases without Requirements Assignment
unc.forProject	for test project
unc.testProject	Test Project
unc.testCases	test cases
unc.matchCount	Match count
unc.noReqSpec	There are no Requirement Spec. defined
unc.noRequirements	There are no Requirements defined
unc.allCovered	All Test Cases are covered
unc.elapsedSeconds	Elapsed seconds

4. Permission Path and Empty States

• No session → 401; missing testplan_metrics (global role) → 403
• has_reqspec=false → info icon + unc.noReqSpec
• has_requirements=false → info icon + unc.noRequirements
• has_data=false → check icon + unc.allCovered (also the DataTable emptyTable message)
• Normal → DataTable grouped by suite

5. BFF API Reference

GET ?action=uncovered_testcases&tproject_id=N

Returns project-scoped test cases with no requirement assignment.

{
  "status": "ok",
  "tproject_id": 1,
  "tproject_name": "Uncovered Demo Project",
  "has_reqspec": true,
  "has_requirements": true,
  "has_data": true,
  "suites": [
    {
      "suite_id": 4,
      "suite_name": "Suite A",
      "tc_count": 1,
      "testcases": [
        { "tc_id": 8, "external_id": "UCD-2", "name": "Uncovered TC" }
      ]
    }
  ],
  "elapsed_time": 0.01
}

6. Files

File	Purpose
gui/templates/results/uncoveredTestCases.html	Modernized HTML/JS screen (Dashio + DataTable + TLi18n)
api/reports/index.php	BFF API (uncovered_testcases action)
cfg/reports.cfg.php	Re-enabled uncovered_testcases entry (enabled='req')
lib/general/asideMenu.php	Aside link (link_report_uncovered_testcases) → uncoveredTestCases.html
gui/templates/i18n/{en,ro,de,fr,es,it,ja,pt,ru,zh}.json	unc.* i18n keys
lib/results/uncoveredTestCases.php	Legacy controller (reference)
lib/functions/testproject.class.php	get_all_testcases_id() (plain list of ids)
lib/functions/requirement_spec_mgr.class.php	get_requirements_count()
