Issue: #1003 Status: IMPLEMENTED & VERIFIED (2026-09-27) — branch task/issue-1003 Screens touched: gui/templates/cfields/cfieldsAssignView.html (front-end only) BFF changes: none — DELETE /api/cfields/{id} already existed and already ran the legacy cascade.

In legacy 1.9.20 the Assign Custom Fields screen links every field name — assigned and available — to lib/cfields/cfieldsEdit.php?do_action=edit&cfield_id=N. That single form offered three actions, not two:

• gui/templates/dashio/cfields/cfieldsEdit.tpl:186-214 — button group of the edit form (the edit-only branch itself is :187-197):

  {if $user_action eq 'edit'  or $user_action eq 'do_update'}
      <input ... name="do_update" value="{$labels.btn_upd}" .../>

      {* Allow delete , just give warning *}
      <input class="{#BUTTON_CLASS#}" type="button" name="do_delete" id="do_delete"
             value="{$labels.btn_delete}"
             onclick="delete_confirmation({$gui->cfield.id},
                     '{$gui->cfield.name|escape:'javascript'|escape}',
                     '{$del_msgbox_title}','{$warning_msg}');"/>
  {/if}
  <input ... name="cancel" ... />

• cfieldsEdit.tpl:29 → {lang_get s='warning_delete_cf' var="warning_msg" }, i.e. locale/en_US/strings.txt:3048 → $TLS_warning_delete_cf = "You are going to delete: %s <br /><br /> Are you sure?"; The confirm box therefore names the field and states the delete is irreversible.
• gui/templates/dashio/include/inc_del_onclick.tpl:29 — delete_confirmation(o_id,o_name,title,msg,pFunction) posts do_action=do_delete back to the same controller.
• lib/cfields/cfieldsEdit.php:61-67 dispatches case 'do_delete' → doDelete() at lib/cfields/cfieldsEdit.php:395-413: get_by_id() → cfield_mgr->delete() → logAuditEvent(TLS("audit_cfield_deleted",$cf['name']),"DELETE",$id,"custom_fields").

The modern assign screen ported only the update half of that legacy entry point:

• gui/templates/cfields/cfieldsAssignView.html:165-168 — the #cfModal footer held only common.cancel and common.save (saveCf()).
• cfieldsAssignView.html:456 / :490 — renderAssigned() / renderAvailable() render the name as onclick="editCf(<id>)"; that modal was the row's only interaction.
• Measured before the change: grep -n "delete\|Delete" gui/templates/cfields/cfieldsAssignView.html → no match. No button, no handler, no request. The sibling list screen gui/templates/cfields/cfieldsView.html:409-425 had 4 matching lines / 7 occurrences of delete, so the capability was assumed to "live on the list screen" — which is exactly why a user reaching a field through Assign could not remove it.

lib/functions/cfield_mgr.class.php:1448-1473:

function delete($id)
{
    if( $this->is_used($id) )        { $this->remove_all_scopes_values($id); }   // 1451-1454
    $linked_tprojects = $this->get_linked_testprojects($id);
    ... foreach($target as $tproject_id) { $this->unlink_from_testproject($tproject_id,(array)$id); }  // 1455-1463
    $sql="DELETE FROM {$this->tables['cfield_node_types']} WHERE field_id={$id}";    // 1465
    ... $sql="DELETE FROM {$this->tables['custom_fields']} WHERE id={$id}";          // 1469
}

remove_all_scopes_values() (:2592-2603) blind-deletes the rows of cfield_design_values, cfield_build_design_values, cfield_execution_values and cfield_testplan_design_values. The unlink loop touches every linked test project, not just the current one. Legacy's generic warning said none of this, so the modern flow states it explicitly — the issue's "with in-use confirmation" requirement, and wording the test suite verified is literally true.

<button type="button" id="btnDeleteCf" class="btn-red" onclick="deleteCfFromModal()"
        style="font-size:13px;float:left;" data-i18n="common.delete">Delete</button>

Placed in the #cfModal footer and floated left, so the order reads Delete | Cancel | Save — the legacy group was Update | Delete | Cancel (cfieldsEdit.tpl:186-214). Measured: Delete at x=99, Cancel at x=530, Save at x=600. It reuses the .btn-red Dashio class already declared in the screen's own stylesheet (:22) and the shared common.delete label — the same convention as the .btn-red Delete in gui/templates/plans/planMilestones.html:190 — instead of a per-screen duplicate key. float:left is correct here: the screen loads Bootstrap 3.4.1 (:8, :178), whose .modal-footer is display:block; it would be ignored on BS4/5 (flex).

var editCfIsUsed = false;
var editCfName = '';
...
editCfIsUsed = !!cf.is_used;
editCfName = cf.name;

is_used was already on the wire (api/cfields/index.php:105, cfToJSON()), previously used only to lock Type/Node Type on used fields. Reusing it means the confirmation needs no extra request.

• Builds the confirmation from cfa.msg.confirmDelete, which carries the whole sentence and a {name} placeholder (same shape as legacy warning_delete_cf). The name is interpolated through TLi18n.t(key, {name: name}) — i18n.js replaces via a function, so a name containing $& or backticks is safe — instead of concatenating a raw name into an English "…"? tail, so the quotes and question mark stay inside each translation.
• Appends cfa.msg.confirmDeleteInUse when is_used is set — exactly the condition under which delete() wipes stored values, so the warning matches the real blast radius.
• On confirm: DELETE /api/cfields/{id} ($.ajax, existing endpoint). The whole modal footer is disabled while the request is in flight — not just Delete — because a Cancel click would dismiss the modal and park the error in a hidden #modalError, and a Save click would PUT a row that is being deleted. Then the modal is hidden, cfa.msg.deleted is toasted and the existing load() runs, which rebuilds both tables, the two counters and the footer info.
• On failure: the server message is shown in #modalError and the modal stays open, so nothing is swallowed. (saveCf() shows its errors the same single-place way.)

cfa.msg.confirmDelete, cfa.msg.confirmDeleteInUse, cfa.msg.deleted in en, ro, de, es, fr, it, pt, ru, ja, zh. The button label reuses the pre-existing common.delete (the repo convention for a .btn-red Delete in a modal footer, see planMilestones.html:190) rather than adding a per-screen duplicate. They are inserted as flat dotted keys in their alphabetical slot, matching the bundles' convention (the repo does not nest these groups), so each file is +3 lines with no reformat. Every file validated with python3 -m json.tool.

Test suite: tmp/TLU_Test_Cases.md → Task — Issue #1003 (14 cases, all PASS).

Measured end-to-end on a fixture where deployment was linked to two test projects and held a design value + a test-plan-design value:

UI after the delete, on the same live page without a reload: modal closed, toast Custom field deleted, assigned table [] with its empty state shown, available table still holds the surviving field, footer recomputed 1 / 2 → 0 / 1, Delete button re-enabled.

Regression matrix (all executed, all PASS): in-use field, unused field, declined confirm (no request, field survives), both tables reloaded, button re-enabled, survivor still editable, i18n completeness ×10, node --check syntax gate, browser console clean, events table free of new Error/Warning rows (every new row is log_level = 16 = tlLogger::AUDIT, lib/functions/logger.class.php:54; ERROR = 1, WARNING = 2).

• cfield_mgr::get_all() (lib/functions/cfield_mgr.class.php:945, INNER JOIN at :961-968) INNER-JOINs cfield_node_types, and cfield_testprojects is keyed on field_id. A custom_fields row without a matching cfield_node_types row is invisible to the whole BFF — a fixture that omits it produces empty tables and an editCf() 404, which looks like a product bug but is not.
• The freshly imported DB ships 0 custom fields and 0 test projects; the fixture SQL is in the test suite.
• The list screen cfieldsView.html keeps its own trash-icon delete; both now call the same BFF route, so behaviour is consistent and only the entry points differ (as in legacy).
