Kruskal - rFronteddu/general_wiki GitHub Wiki

MST-KRUSKAL(G,w)
    A = {}
    for each v in G.V
        MAKE-SET(V)
    sort G.E in nondecreasing order by weight w

    for each (u,v) in G.E, taken in nondecreasing order by weight
        // check whether u,v belong to the same tree i.e. whether we would add a cycle
        if FIND_SET(u) != FIND_SET(v) // FIND_SET returns a representative element from the set that contains u
            add (u,v) to A
            // UNION merges the vertices of two clusters to determine
            // if adding a future edge will produce a cycle
            UNION(u,v)
    return A

// Java program for Kruskal's algorithm

import java.util.ArrayList;
import java.util.List;
import lombok.AllArgsConstructor;

public class KruskalsMST {
    @AllArgsConstructor
    static class Edge {
        int src, dest, weight;
    }

    @AllArgsConstructor
    static class Subset {
	int parent, rank;
    }

    // Starting point of program execution
    public static void main(String[] args) {
        // ... init edges and vertices
        // List<Edge> graphEdges = ...
        // int V = ...
	kruskals(V, graphEdges);
    }

    // Function to find the MST
    private static void kruskals(int V, List<Edge> edges) {
	// Sort the edges in non-decreasing order
	graphEdges.sort((e1, e2) -> { return e1.w - e2.w; })

	Subset subsets[] = new Subset[V];
	Edge results[] = new Edge[V];

	// Create V subsets with single elements
	for (int i = 0; i < V; i++) {
	    subsets[i] = new Subset(i, 0);
	}

        int j = 0;
	int noOfEdges = 0;

	// Number of edges to be taken is equal to V-1
	while (noOfEdges < V - 1) {
            // Pick the smallest edge. And increment the index for next iteration
	    Edge nextEdge = edges.get(j);
	    int x = findSet(subsets, nextEdge.src);
	    int y = findSet(subsets, nextEdge.dest);

	    // If including this edge doesn't cause cycle, include it in result and increment the index
	    // of result for next edge
	    if (x != y) {
	        results[noOfEdges] = nextEdge;
		union(subsets, x, y);
		noOfEdges++;
	    }
	    j++;
	}

        printResult (results, noOfEdges);
    }

    // Function to find parent of a set
    private static int findSet(Subset[] subsets, int i) {
        if (subsets[i].parent == i)
	    return i;

	subsets[i].parent = findSet (subsets, subsets[i].parent);
	return subsets[i].parent;
    }

    // Function to unite two disjoint sets
    private static void union(Subset[] subsets, int x, int y) {
        int rootX = findSet(subsets, x);
	int rootY = findSet(subsets, y);

	if (subsets[rootY].rank < subsets[rootX].rank) {
	    subsets[rootY].parent = rootX;
	}
	else if (subsets[rootX].rank < subsets[rootY].rank) {
	    subsets[rootX].parent = rootY;
	}
	else {
	    subsets[rootY].parent = rootX;
	    subsets[rootX].rank++;
	}
    }

    private static void printResult(Edge[] results, int noOfEdges) {
	// Print the contents of result to display the  built MST
	System.out.println ("Following are the edges of the constructed MST:");
	int minCost = 0;
	for (int i = 0; i < noOfEdges; i++) {
	    System.out.println (results[i].src + " -- "+ results[i].dest + " == "+ results[i].weight);
	    minCost += results[i].weight;
	}
        System.out.println ("Total cost of MST: " + minCost);
    }
}
