The device was given to me by Devin Paden to borrow for the extent of this project. The following information is all of the specifications and parts of this device.

Product Specifications:

Part Details
CPU Intel Celeron Quad Core J1900 (64 Bit, 2.0 GHz, 4 Cores, 4 Threads, 2MB L2 Cache)
GPU Integrated Intel HD Graphics
RAM 1x Samsung 4GB 2Rx8 PC3L-12800S-11-10-F3
Storage 8GB SSD

Front:

rsz_1protectli_box2

Details:

  • 4 Intel® Gigabit 82583V Ethernet NIC ports
  • DC 12V input
  • Indicator lights

Back:

rsz_protectli_box_back

Details:

  • 1 VGA port
  • 2 USB 2.0 ports
  • Power button
  • 2 Wireless antenna ports

coreboot

coreboot provides a boot-firmware solution that is secure, fast and reliable. Millions of devices around the world already run on coreboot:

  • Fast, light-weight and secure BIOS
  • Get maximum security, transparency, and audit-ability
  • Select during configuration of your Vault (see compatible models below)
