API Governance - dennisholee/notes GitHub Wiki

Objectives

General Policies

Committees

  • API Governance Committee
  • API Steering Committee

Enterprise Goals and Alignment Goals

Policies System

Information and Reports

Organizational Structures

Services, Programs and Infrastructure of Information Technology

Knowledge, Skills and Experiences

Principles

Principle 1: Provide stakeholder value

Principle 2: Holistic Approach

Principle 3: Dynamic Governance System

Principle 4: Governance Distinct from Management

Principle 5: Tailored to Enterprise Needs

Principle 6: End-to-End Governance System

Culture Change Capacity Collaborate
Information Maturity Change Capacity Collaborative Readiness

API Catalogue (API Portal)

https://www.sensedia.com/post/api-architecture-maturity-model

Idempotent REST APIs

Content Negotiation

Server-driven vs Agent-driven Content Negotiation

  • HTTP Headers
    • Content-Type: application/json
    • Accept: application/json
  • URL Patterns
    • HTTP://.../page.xml
    • HTTP://.../page.json

REST Resource Representation Compression

Accept-Encoding

  • compress
  • gzip Content-Encoding

Versioning

Payload Encryption

Envelope Key exchange

API Authentication

Src: https://www.openidentityplatform.org/blog/stateless-vs-stateful-authentication

Considerations Stateful Stateless
Session information could be stolen ✅ It is impossible to steal session information from the session identifier because it is just an identifier associated with the session ⛔Session identifier contains all authentication information and it is possible to steal sensitive information, it is not encrypted.
Resource consuming ⛔When retrieving session information, the service always gets access to session storage which causes additional resource consumption. ✅The session identifier contains all session information.
Easy to implement ⛔When session information is stored in an external database, there is a need to implement session database persistence. ✅Session identifier contains all session information, there is no need to implement additional functionality
Easy to scale ⛔While adding new instances, there is a need to implement additional scale to session storage as well ✅ Adding new service instances does not require additional effort
Possibility to compromise session data. ✅Only the authentication system is able to retrieve session information from an authentication token, so there are no more vulnerabilities. ⛔To decrypt session information from a token, all parts of the system should share the same key. And, if at least one system is compromised, all parts of the system are under the threat.
Authentication token size ✅An authentication token is just an identifier, so session data does not affect its size. ⛔If an authentication session contains a large amount of data, the authentication token also becomes large, which can cause additional load on a network.
Restrict access among different parts of an application ✅It is possible to configure the system so different parts of the system will only have access to the data necessary for their work ⛔All parts of the system have access to all session data
Possibility to revoke session ✅It is possible to revoke a session at any time ⛔Since the session token contains an expiration date, it is impossible to revoke the authentication session
Possibility to modify session data ✅It is possible to modify any session data in session data storage. ⛔Since the session token contains all session data, it is not possible to modify it
SSO implementation ✅The integration of different parts of the system is possible without modification of the source code, session information can come through the authentication system gateway. ⛔Changes must be made to each part of the system to retrieve data from an authentication token

JWT Generation

Firewall - PUT etc.

Roles and Responsibilities

Roles Responsibilities
API Architect API Policies
API Designer Create API spects
API Developer Implement API,
API Tester
DevOps

Define and Communicate Policies and Procedures

API Champions

Define and Implement Infrastructure, Services and Application to Support the Governance and Management System.

  1. Identify priority management objectives that may be achieved by automating services, applications or infrastructure.
  2. Select and implement the most appropriate tools and communicate to stakeholders.
  3. Provide training on selected tools, as required.

Manage Continual Improvement of the I&T Management System

Evaluate, Prioritize and Authorize Change Requests

Categorize changes Impact Assessments

Risk assessment - Low - pre-approved

| | | | Target service consumers | Open, Partnership, Private | | Information

Service tier
