MosquitoFBMkVI - asherao/DCS-ExportScripts GitHub Wiki
| ID | Description | Status | Output e.g. |
|---|---|---|---|
| 4000 | Engine Instruments Left Tile 1 | Working | ENG L RPM 1,234 Boost 14 |
| 4001 | Engine Instruments Left Tile 2 | Working | Oil T 89°C Oil P 75 Rad T 99°C |
| 4002 | Engine Instruments Right Tile 1 | Working | ENG R RPM 1,234 Boost 14 |
| 4003 | Engine Instruments Right Tile 2 | Working | Oil T 89°C Oil P 75 Rad T 99°C |
| 4004 | Gun Sight Solution Tile | Working | Gun Sight Rng 321 YA Base 32 ft BF109 |
| 4005 | Fuel Inner Tanks Tile | Working | Fuel Inner PORT 15 STBD 16 Total 31 |
| 4006 | Fuel Center Tanks Tile | Working | Fuel Center №10 4 №12 5 Total 9 |
| 4007 | Fuel Outer Tanks Tile | Working | Fuel Outer Port 25 STBD 26 Total 51 |
| 4008 | Fuel Total Tanks Tile | Working | Inner 100 Center 10 Outer 40 Fuel Tot 150 |
| 4009 | Pilot Radio Tile | Working | Radio A 123.450 |
| 4010 | T1154 Radio Blue Tile 1 | Working | Blue Radio A 9.255 B 8.000 C 7.710 |
| 4011 | T1154 Radio Blue Tile 2 | Working | D 6.805 E 5.595 F 5.850 G 5.700 |
| 4012 | T1154 Radio Red Tile 1 | Working | Red Radio J 5.250 K 5.000 L 4.750 |
| 4013 | T1154 Radio Red Tile 2 | Working | M 6.500 N 7.250 P 4.250 Q 3.012 |
| 4014 | T1154 Radio Yellow Tile 1 | Working | Yellow Radio S 444.000 T 421.000 U 303.000 |
| 4015 | T1154 Radio Yellow Tile 2 | Working | V 300.000 W 270.000 X 259.000 Y 250.000 |
| 4016 | R115 and T1154 Radio Tile | Working | R1155 5.123 T1154 9.456 |
| 4017 | Air Temperature Tile | Working | Air Temp 25°C |
| 4018 | Navigation Tile 1 | Working | HDG 056 PNT 1 005 PNT 2 245 |
| 4019 | Altimeter Dial Tile | Working | Altitude 1,234 ft 950 mbar |
| 4020 | Instruments Tile | Working | Instruments 250 mph 1,234 ft -2,500 fpm |
| 4021 | Trim Tile | Working | TRIM ELV 10% D RUD 15% S AIL 10% L |
| 4022 | BombBay, Gear, Flap Tile | In Progress | External Gear is Down Flaps 25 BBay Closed |
| 4023 | Pilot Oxygen Tile | Working | Oxy Pilot Flow 0k ft Amt. 100 |
| 4024 | Copilot Oxygen Tile | Working | Oxy Copilot Flow 35k ft Amt. 78 |
| 4025 | Oxygen Tile | Working | P Flow 0k ft P Amt. 100 CP Flow 0k ft CP Amt. 100 |
| 4026 | Takeoff Power Tile | Working | Takeoff 5 RPM 3,000 Boost +12 |
| 4027 | Intermediate Power Tile | Working | Inter. 60 RPM 2,850 Boost +9 Rad 125°C Oil 90°C |
| 4028 | Max Continous Power Tile | Working | Max Cont. RPM 2,650 Boost +7 Rad 105°C Oil 90°C |
| 4029 | Emergency Power Tile | Working | Emergency 5 RPM 3,000 Boost +25 Rad 125°C Oil 105°C |
| 4030 | Max Rate Climb Tile | Working | Max Rate CLB RPM 2,850 Boost +9 Low Gear 150 mph |
| 4031 | Max Range Climb Tile | Working | Max Range CLB RPM 2,650 Boost +7 Low Gear 150 mph |
| 4032 | Best Cruise Tile | Working | Best Cruise RPM Min Boost +7 AUTO Gear 200 mph |
| 4033 | Approach Speed Tile (Changes to glide at Idle) | Working | Landing 17k FLAP DOWN 125 mph FLAP UP 140mph |
| 4034 | Max Speeds Tile 1 | Working | Slick 370 mph Tanks 330 mph R.P. 350 mph Ext. 305 mph |
| 4035 | Max Speeds Tile 2 | Working | BBay 305 mph Gear 155 mph F25° 175 mph FDWN 130 mph |
| 4036 | Stall Speeds Tile | Working | Stall Speeds Ret. 105 mph Ext. 100 mph App. 95 mph |
| ----- | ----- | ----- | ----- |
| 3000 | Eng Left RPM | Working | 1234 |
| 3001 | Eng Left Boost | Working | -5 |
| 3002 | Eng Left Oil Temp | Working | 100 |
| 3003 | Eng Left Oil Pressure | Working | 68 |
| 3004 | Eng Left Radiator Temp | Working | 90 |
| 3005 | Eng Right RPM | Working | 1234 |
| 3006 | Eng Right Boost | Working | -5 |
| 3007 | Eng Right Oil Temp | Working | 100 |
| 3008 | Eng Right Oil Pressure | Working | 68 |
| 3009 | Eng Right Radiator Temp | Working | 90 |
| 3010 | Gun Sight Range | Working | 312 |
| 3011 | Gun Sight Span | Working | 45 |
| 3012 | Gun Sight Optimal Target | Working | Optimal Target BF109 |
| 3013 | Fuel Inner Tank Left | Working | 15 |
| 3014 | Fuel Inner Tank Right | Working | 16 |
| 3015 | Fuel Inner Tank Total | Working | 31 |
| 3016 | Fuel Center No10 Tank Left | Working | 4 |
| 3017 | Fuel Center No12 Tank Right | Working | 5 |
| 3018 | Fuel Center Total | Working | 9 |
| 3019 | Fuel Outer Tank Left | Working | 25 |
| 3020 | Fuel Outer Tank Right | Working | 26 |
| 3021 | Fuel Outer Tank Total | Working | 51 |
| 3022 | Fuel Total | Working | 150 |
| 3023 | R1155 Receiver Freq | Working | 5.123 |
| 3024 | T1154 Transmitter Freq | Working | 9.456 |
| 3025 | Pilot Radio Freq | Working | 123.450 |
| 3026 | Pilot Radio Button | Working | A |
| 3027 | Air Temperature | Working | 25 |
| 3028 | Compass Dial Readout | Working | 059 |
| 3029 | Compass Dial Needle 1 Readout | Working | 005 |
| 3030 | Compass Dial Needle 2 Readout | Working | 236 |
| 3031 | Altimeter Readout | Working | Altimeter 1,234 ft |
| 3032 | Pressure Readout | Working | Pressure 950 bmar |
| 3033 | Airspeed Readout | Working | Airspeed 250 mph |
| 3034 | Vertical Speed Readout | Working | VS 2,000 fpm |
| 3035 | Elevator Trim Readout | Working | ELV TRM 10% UP |
| 3036 | Rudder Trim Readout | Working | RUD TRM 15% PORT |
| 3037 | Aileron Trim Readout | Working | AIL TRM 2% Right |
| 3038 | (is) Gear Up | In Progress | 1 if up, 0 if not |
| 3039 | (is) Gear Down | In Progress | 1 if down, 0 if not |
| 3040 | Flap Indicator | Working | 45 |
| 3041 | Pilot Oxygen Flow Rate | Working | 15 |
| 3042 | (is) Pilot Oxygen Flow Emergency | Working | 0 = no, 1 = yes |
| 3043 | Pilot Oxygen Supply | Working | 98 |
| 3044 | (is) Pilot Oxygen Supply Red Zone | Working | 0 = no, 1 = yes |
| 3045 | Copilot Oxygen Flow Rate | Working | 15 |
| 3046 | (is) Copilot Oxygen Flow Emergency | Working | 0 = no, 1 = yes |
| 3047 | Copilot Oxygen Supply | Working | 98 |
| 3048 | (is) Copilot Oxygen Supply Red Zone | Working | 0 = no, 1 = yes |
| 3049 | (is) Pilot Oxygen Emergency | Working | 1 if any pilot oxygen dial is emergency. 0 otherwise. |
| 3050 | (is) Copilot Oxygen Emergency | Working | 1 if any copilot oxygen dial is emergency. 0 otherwise. |
| 3051 | (is) Either Oxygen Emergency | Working | 1 if any oxygen dial is emergency. 0 otherwise. |
| 3052 | (is) Aircraft Stall | Working | 1 below 105 kts. 0 otherwise. |
| ----- | ----- | ----- | ----- |
| 8000 | Aircraft Name | Done | MosquitoFBMkV |
| 8001 | Player Name | Done | New Callsign |
| 8002 | Time | Done | Real Time 07-25-56 DCS Time 18-00-25 |
| 8003 | Instrument Panel US | Done | HDG 145º ALT 14,440 ft IAS 345 kts V/S 3,800 ft/min |
| 8004 | Instrument Panel RU | Done | HDG 145º ALT 9,710 m IAS 130 km/h V/S 16 m/s |
| 8005 | Instrument Panel WW2 | Done | HDG 145º ALT 14,440 ft IAS 320 mph V/S 3,800 ft/min |
| 8006 | Lat Long DMS | Done | Lat-Long-DMS N 40º46'21.49' E 44º06'45.01' |
| 8007 | Lat Long DDM | Done | Lat-Long-DDM N 40º46.358' E 44º06.750' |
| 8008 | MGRS | Done | MGRS 38 T ML 25103 13896 |
| 8009 | Magnetic Variance/Deviation | Done | Mag Var 6.42 |
| 8010 | Fuel Consumption (left) | Done | 4,000 |
| 8100 | Wind Aloft | Done | 304º 8kts |
| 8101 | Closest Airport (preferred runway based on winds) |
Done | Nalchik 047º 32nm ETE 00-06-25 340º 3kts 06-24 (24) |
| 8102 | Second Closest Airport (preferred runway based on winds) |
Done | Senaki 178º 62nm ETE 00-08-24 311º 3kts 27-09 (09) |
| 8200 | Ground Radar Enemy 1 | Done | Enemy Ground house2arm 324º 15nm |
| 8201 | Ground Radar Enemy 2 | Done | No Ground Enemy Detected |
| 8202 | Ground Radar Friend 1 | Done | Friend Ground Predator GCS 262º 184nm |
| 8203 | Ground Radar Friend 2 | Done | No Ground Friend Detected |
| 8210 | Air Radar Enemy 1 | Done | Enemy Air Su-27 235º 17nm |
| 8211 | Air Radar Enemy 2 | Done | No Air Enemy Detected |
| 8212 | Air Radar Friend 1 | Done | Friend Air F-16C bl.52d 211º 15nm |
| 8213 | Air Radar Friend 2 | Done | No Air Friend Detected |
| 8666 | Igla Hunter Search Mode | Done | Igla Hunter Searching... |
| 8666 | Igla Hunter Detect Mode | Done | Igla Detected SA-18 Igla comm 297º 28nm |
