Main Page >> Engine Bay Sensors >> Fuel Pressure Sensor
Last update 24-04-2024
Part number: 31272730. BOSCH 0 261 230 238. Sold on AliExpress here
| PIN | Function | Electrical Data |
|---|---|---|
| Pin 1 | Ground | GND |
| Pin 2 | Temperature Signal | 0.4V-4.65V DC |
| Pin 3 | Power Supply | +5V DC |
| Pin 4 | Pressure Signal | 0.4V - 4.65V DC |
| T [°C] | R [Ohm] |
|---|---|
| -40 | 45,303 |
| -30 | 26,108 |
| -20 | 15,458 |
| -10 | 9,395 |
| 0 | 5,895 |
| 10 | 3,791 |
| 20 | 2,499 |
| 25 | 2,056 |
| 30 | 1,706 |
| 40 | 1,174 |
| 50 | 833.8 |
| 60 | 595.4 |
| 70 | 435.6 |
| 80 | 322.5 |
| 90 | 243.1 |
| 100 | 186.6 |
| 110 | 144.2 |
| 120 | 112.7 |
| 130 | 89.28 |
Tutorial Video for replacement of this sensor (by FCP Euro)
🟢 Fully tested and working
