Turn Restrictions Best Practices - TelenavMapping/Telenav_mapping_team_practices_and_workflow GitHub Wiki

Turn restrictions in intersections indicates if there's a maneuver that can't be done(ex: no right turn, no U turn etc.), or a maneuver that can be done(ex: only left turn, only straight).

Classic Turn Restriction
type=restriction
restriction =* ex: no_left_turn, only_straight_on
Time Based Turn Restriction
type = restriction
restriction:conditional=* ex: no_left_turn @ (Mo-Fr 10:00-12:00), only_straight_on @ (Mo-Fr 10:00-12:00;Sa-Su 15:00-19:00)
Other tags
except=* ex: psv, bicycle, emergency

FROM


TO


VIA

example: restriction=no_left_turn



example: restriction=only_straight_on



restriction:conditional=no_left_turn @ (Mo-Fr 07:00-09:00,15:30-17:30)



example: except=bicycle

• If the restriction it's applied to a one way, don't add it because if you do it will be duplicate information.

• On Time Based Turn Restriction be sure you don't let any extra "spaces" in the syntax..
