1. hide views



2. Extrude: you can do remove to remove a part

   • blind -> up to next is a good idea



3. move shape:

   • use dimension:



   • move 3d shape



4. Copy a shape

5. align two point



6. construct a line: lq

   • 'q' is the shortcut for construction, and 'l' is the shortcut for line.
   • select mid point:



7. construct a semi-circle



8. trimming:



9. Revolve: always sketch the half of an object!

10. Measure, resize

    • "Transform", and choose "Scale uniformly"
    • default unit
