| 1 |
Spoorthi B |
Arduino, Multipurpose PCB, 2 Stepper motor |
bearings, nuts, bolts, pulley, belt drive |
Belt drive mechanism |
https://youtu.be/CWu26Ys8zlI |
| 2 |
|
Arduino UNO, Photoelectric Speed Sensor, Servo Motor, DC Motor |
nuts, bolts, rods, clips |
|
https://youtu.be/tsxu_KMYnTs |
| 3 |
|
AVR microcontroller, LCD, Opto-interrupt Sensor, DC Motor |
bobbins, push buttons, conveyor belt |
Close Loop Control System |
https://www.engineersgarage.com/dc-motor-speed-and-rotation-control/ |
| 4 |
Uday K |
DC Motor, ZigBee, Sensor IR Sensor, Vibration Sensor, Proximity Sensor |
I/O Ports, Port A And Tris A Register, Port B And Tris B Register |
Pre defined value based, Proximity sensor based |
file:///C:/Users/HP/Downloads/automaticthreadwindingmachine.pdf |
| 5 |
|
775 DC Motor liner rails, HMI Optical Encoder, nema 17 stepper motor, 5mm ID bearings Custom PCB, CNC router machine |
timing belt 6mm, timing pulley 6mm, profile Nextion 20 x 20, 6mm acrylic sheet |
* pull-up resistor, *conveyer belt, *Optical Rotary Encoder |
https://hackaday.io/project/185816-diy-thread-winding-machine/details |
| 6 |
|
MSP430 microcontroller, TEXAS LAB, Nema17 stepper motor, DC Motor, 16x2 LCD, L293d Motor Driver, SG90 Servo Motor, 5v 2a Adapter |
Msp430g2 development board, A4988 stepper driver, |
|
https://ijirt.org/master/publishedpaper/IJIRT155648_PAPER.pdf |
| 7 |
Ankita Angadi |
DC motor, LED screen, Energia IDE, stepper motor, rotatory encoder, Arduino, stepper driver |
nuts, bolts, pulley, bearings, clamps, belt drive |
Belt drive mechanism |
https://youtu.be/QKXp0W79DrQ |
| 8 |
|
Arduino 2650, Nema 17 stepper motor, Stepper driver A4988, display |
3D printed parts, bearings, threaded rod |
Bevel gear mechanism |
https://youtu.be/nJKxa9mhLuI |
| 9 |
|
Arduino UNO, 0.96" OLED display, encoder knob, DC motor, servo motor, L23D IC, photoelectric speed sensor |
clamps, pulley |
|
https://youtu.be/tsxu_KMYnTs |
| 10 |
Pranav G Bhat |
servo motor, IR sensor,LCD display,Nema stepper motor,775 Dc motor |
scrap sheet,metal sheet,12mm plywood sheet,window rollers |
belt mechanism |
https://youtu.be/46rbpPwqelY |
| 11 |
|
Arduino, servo motor, stepper motor ,dc motor |
bearings, nuts ,bolts,clamps,belt drive |
Conveyar belt mechanism |
https://youtu.be/GBbT6FhckXM |
| 12 |
|
12 volt dc motor, stepper motor, LED display |
pulley, rod, nuts, bolts, clamps |
slider mechanism |
https://www.youtube.com/watch?v=V7duQAd-BmQ |
| 13 |
Yashawant Danaraddi |
load cell ,tension controller |
tension rollers, brakes |
Tension control system |
https://youtu.be/0GKzflZgbDI |
| 14 |
|
dc motor |
roller |
traverse winding theory |
https://youtu.be/Fv-2Yl2A_KE |
| 15 |
|
|
|
|
|
