Pulse Cannon: make space while firing

AoA 3.7.1 / Minecraft 1.20.1. Source-grounded concept candidate; no accepted native upgrade.

What it does

Pulse Cannon combines an inherited cannonball shot with a separate nearby-hostile repulsion effect around the shooter when firing. The inspected firing-effects override calls its parent first, queries living entities using the hostile-mob predicate in the shooter's bounding box inflated by 2.5, then calls the push-away helper with input 0.75.

That is not an impact-centered explosion, not a guaranteed 2.5-block spherical radius, and not proof of a 0.75-block displacement. Keep the shot, shooter-centered pulse and any proposed decorative shockwave distinct.

Released input	Value / boundary
Registry ID	aoa3:pulse_cannon
Damage constructor input	26; final damage depends on native paths
Durability constructor input	510
Firing delay	42 ticks, nominally 2.1 seconds at 20 TPS
Constructor recoil	0.15; not camera degrees
Ammunition	Cannonball inherited from BaseCannon
Projectile	CannonballEntity inherited from BaseCannon
Projectile constructor inputs	Age 120, piercing 0
Nearby query	Shooter AABB inflated by 2.5; hostile-mob predicate
Push-away helper input	0.75; not measured final motion
Sound	ITEM_SHADOW_BLASTER_FIRE

Original identity

The actual sprite has a compact charcoal frame, large rectangular forward opening, magenta/purple rails and housings, bright horizontal pink accent, stepped upper blocks and an angled rear grip. Those landmarks should remain recognizable in both Minecraft-fit and concept-faithful visual treatments. The new concept's panel construction and energy materials are interpretations; this study establishes no official manufacturer or dimension origin.

Crafting and upgrade lineage

The released infusion recipe uses Cannon Frame as its input, with Purple Druse, Red Druse, Power Core, Unstable Gunpowder and two iron-ingot tag entries, producing Pulse Cannon. It is an aoa3:infusion recipe, not a vanilla grid.

Pulse Cannon + Clown Upgrade Kit → Clowno-Pulse through the released upgrade-kit recipe. Preserve the parent/child distinction when offering attachments or craftable alternatives.

New concept candidate

The rectangular muzzle and paired structural rails remain prominent, with purposeful dark surfaces and restrained magenta lighting. The sheet includes a shroud option, angular sight and two different effect studies. It is not an in-game capture or a completed implementation.

Before model approval, shorten any excessive elongation against the source silhouette and refine explicit trigger/guard geometry, comfortable real hand placement and the support grip. A polished image cannot certify hand clearance. The illustrated defensive pulse omits the holder for clarity; its eventual visual origin must follow the shooter, not a dropped gun or projectile impact.

The debris and pink ring are proposals. They must not create terrain damage, additional entity damage, or changed push range without an explicit gameplay attachment and server-authoritative implementation.

Complete feature direction

• Shot and feedback: one readable cannonball launch, a brief rectangular muzzle pulse, weighty recoil/recovery and a short fading trail. Preserve the separate defensive effect.
• Pulse presentation: a bounded shooter-centered wave at valid firing time, with reduced-flash/reduced-motion options. Cosmetic rings should not imply a precise spherical hit boundary the source does not use.
• Attachments: open-frame versus shrouded muzzle, adjustable angular sight, supported grip, pulse visualization module and optional resource-service housing. Show functional values and conflicts instead of treating geometry as implementation.
• Inspection: sequential magenta panel activation, a contained rectangular field test, then exact neutral-pose restoration; cancellation must clean up all effects.
• Reload/service: optional, appropriate to Cannonball accounting. No hidden new magazine requirement or duplicated ammo.
• Customization and progression: separate skins, earned functional charms, stickers/emblems, projectile/trail/impact/decal/finisher options, dismantling rules and craftable alternates.
• Native animation: equip, idle, aim, movement, fire, recovery, inspect and any service transitions with actual wide/slim player arms and swept clearances.
• Performance: bounded pulse/projectile effects, stable startup and frame-time budgets, exact-version dependency qualification and no repeated scans.

Tests that matter for this weapon

• Capture the original shot and pulse in the pinned game build.
• Confirm effect ordering, valid firing conditions, projectile count and resource conservation.
• Test query corners versus face-center positions; do not replace the source AABB with a sphere accidentally.
• Check friendly entities, hostile predicate edge cases, bosses, knockback resistance and protected environments.
• Verify multiplayer authority and avoid applying the push once per render pass or once per client.
• Test saves, upgrades, attachments, interrupted animation, actual materials and equivalent-work performance.

Source receipt · Mandatory complete weapon standard.

Original AoA identity and assets: Tslat and contributors. New concept generated with the built-in image tool. All native and final art acceptance gates remain open.

Recoil interpretation

For this pinned 1.20.1 release, the stored constructor recoil input is not the inherited modifier getter: the inspected BaseGun.getRecoilModifier() returns approximately 0.35. The per-shot method and later client application determine the actual recoil path. Do not infer a stronger or weaker measured kick from the constructor column alone. This clarification does not change the original values, weapon balance or acceptance state. Resolved method routing.
