5. VIRTUAL IMPLEMENTATION - E-division-2022-2023-odd/Repo-10 GitHub Wiki
| SI.No | PART NAME | MATERIALS WITH WHICH THE PARTS IS MADE OF | DESCRIPTION ABOUT THE PART | QUANTITY REQUIRED | FABRICATION PROCESS IF NEEDED |
|---|---|---|---|---|---|
| 1 | Arduino Mega 2560 | - | AT2560 | 1 | - |
| 2 | Micro servo | - | Sg,180* | 1 | - |
| 3 | Small Reduction Stepper Motor | - | 5v DC | 1 | - |
| 4 | DC Motor | - | 12V 2A | 2 | - |
| 5 | wall Adapter power supply | - | 12V DC 2A | 1 | - |
| 6 | LED | - | Blue | 1 | - |
| 7 | Buzzer | - | - | 1 | - |
| 8 | Resistor | - | 220 ohm | 1 | - |
| 9 | Breadboard | - | - | 1 | - |
| 10 | Motor Clamp | Plastic | use to fix the Motor hard and tough | 2 | Cutting Bending |
| 11 | Screw and Nuts | metal | Framing screws(0.44*0.14inch) | 20 | - |
| 12 | Acrylic sheet | - | 1 Feet^2 | - | Cutting Bending |
| 13 | ON-OFF | - | - | 1 | - |
| 14 |
Step1:start.
Step2:detect music.
Step3:Ask for user input
Step4:legs need to move
step5: if input is true,turn on LED
step6:if input is false,turn off LED
Step7:stop
