4. Morphological Chart and Concept Design - A-Division-2021-2022-Odd/Repo-04 GitHub Wiki
4.1 Activity
| TEAMS | FUNCTION FROM DESIGNER PERSPECTIVE |
|---|---|
| 1 | Movement of legs |
| 2 | Make beep sound when it is on |
| 3 | Light should appear in eyes of bot |
| 4 | It should be a obstacle avoiding bot |
| 5 | It should be controlled by remote |
| 6 | It should have on & off button |
| 7 | It should play some music |
| 8 | Casing |
4.2 FUNCTION TREE
4.3 MORPHOLOGICAL CHART
| serial no | Sub function | Means 1 | Means 2 | Means 3 | Means 4 |
|---|---|---|---|---|---|
| 1 | Light from eyes and indication | LED light  |
Normal bulb  |
- | - |
| 2 | Movement of body parts | Linkage mechanism |
Pin Joint  |
Rocker Mechanism |
|
| 3 | Play Music and sounds | Small Speakers |
Buzzer |
- | - |
| 4 | Obstacle avoiding | ultrasonic sensors |
Proximity sensors |
Infrared sensor |
IR sensor Transmissible type |
| 5 | Control | Remote |
Phone |
- | - |
| 6 | input methods | Mike  |
Touch sensor  |
Programmable switches  |
Radio receiver  |
| 7 | Casing materials | PU plastic |
leather |
Silicon |
4.4 Concept Design
